Glass bottle infusion stoppering and capping oral liquid filling line
- Category: >>>
- Supplier: Shanghai Universal Pharmaceutical Machinery Co. Ltd.
Share on (1600433758615):
Product Overview
Description
Product Overview
Glass bottle infusion stoppering and capping oral liquid filling line
50ML-500ML glass bottle
Automatic bottle unscramble turntable, filling and plugging, capping and capping equipment information
(1) Composition:
Bottle unscramble turntable→liquid filling and stoppering machine (optional for hundred-level laminar flow hood customers) →
automatic capping and capping machine (optional for hundred-level laminar flow hood customers) → connecting to the subsequent
process
Automatic bottle unscramble turntable, filling and plugging, capping and capping equipment information
(1) Composition:
Bottle unscramble turntable→liquid filling and stoppering machine (optional for hundred-level laminar flow hood customers) →
automatic capping and capping machine (optional for hundred-level laminar flow hood customers) → connecting to the subsequent
process
FEATURES AT A GLANCE
Technical characteristics of main equipment
1. L-SP series automatic bottle unscramble turntable:
This machine is composed of a bottle unscrambler tray and a bottle conveying track, which plays a role of storage, buffering and
steering in the assembly line.
1. 900 mm diameter bottle feeding disc with feeding platform for convenient feeding
2. With independent motor, the speed can be adjusted separately and connected with the filling machine.
3. 304 stainless steel chassis
4. With four adjustable fixed feet
1. L-SP series automatic bottle unscramble turntable:
This machine is composed of a bottle unscrambler tray and a bottle conveying track, which plays a role of storage, buffering and
steering in the assembly line.
1. 900 mm diameter bottle feeding disc with feeding platform for convenient feeding
2. With independent motor, the speed can be adjusted separately and connected with the filling machine.
3. 304 stainless steel chassis
4. With four adjustable fixed feet
Vibrating plug
automatic bottle unscramble turntable
Electrical box
PRODUCT SPECIFICATIONS
No | Item | Data | ||
1 | Power | 4.5 kW | ||
2 | Compressed air | 0.3MPa～0.4MPa | ||
3 | Measuring accuracy | ±1-2% | ||
4 | Filling method | Peristaltic pump filling | ||
5 | Plugging method | Electromagnetic oscillation plugging | ||
6 | Number of plugs | 2 | ||
7 | Bottle in and out method | conveyor belt | ||
8 | Plugging rate | ≥98% |
PRODUCT CONFIGURATION
Siemens
Inside turntable
Stainless steel
