Factory Price 37M 49M 52M 58M 62M 70M Euro V Truck-Mounted Concrete Pump HB52V HB49V HB58V HB62V HB70V
Products Description
52m concrete pump truck HB52V.
The HB52V concrete pump truck is equipped with more efficient skirt valve and S valve pump technology, more stable reversing
buffer technology, more reliable full hydraulic reversing technology.
It adopts great chassis, which complies with China VI emission standard, featuring with powerful output, large torque, high
efficiency, energy conservation and strong off-road performance.
The HB52V concrete pump truck is equipped with more efficient skirt valve and S valve pump technology, more stable reversing
buffer technology, more reliable full hydraulic reversing technology.
It adopts great chassis, which complies with China VI emission standard, featuring with powerful output, large torque, high
efficiency, energy conservation and strong off-road performance.
Advantages and highlights:
1.Ultimately Safe Boom.
2. Lower Structure of High Rigidity.
3.Hydraulic System of Outstanding Performance.
4.Effectively reduce emissions with the reversing, vulnerability of longer life.
5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.
6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.
1.Ultimately Safe Boom.
2. Lower Structure of High Rigidity.
3.Hydraulic System of Outstanding Performance.
4.Effectively reduce emissions with the reversing, vulnerability of longer life.
5.The pumping system adopts electric control reversing, reversing faster and the system impact smaller.
6.The actual pumping efficiency is more than 5% higher than the conventional hydraulic control reversing system.
Product Paramenters
Item | Unit | HB52V | ||
Outline dimension | mm | 13000×2540×4000 | 12950×2540×4000 | |
Overall weight | kg | 35000 | 35000 | |
Brand | / | Sinotruk | Benz | |
Model | / | ZZ5356V524ME1 | AROCS3343 | |
Wheelbase | mm | 4800+1400 | 4800+1350 | |
Max.power | kW | 324 | 315 | |
Emission standard | / | ChinaV | ChinaV | |
Theoretical | m³/h | 170 | ||
Concrete pumping pressure | MPa | 8 | ||
Theoretical pumping times | Times/min | 23～26 | ||
Delivery cylinder diameter × stroke | mm | φ260×2000 | ||
Reach height | m | 51.2 | ||
Reach depth | m | 36.1 | ||
Slewing radius | m | 46 | ||
Slewing angle | ° | ±270 | ||
Transfer | / | Rock valve/S valve | ||
