Common coarse powder/particle screening equipment - Rectangular vibrating screen
The Rectangular vibrating screen produced by Yuanzhen Machinery uses dual vibrating motors as the vibration source, so that the material is thrown up on the screen and at the same time linearly jumps to the discharge port, and the material enters the feed of the screening machine evenly from the feeder Through the multi-layer screen, the oversize and undersize items of various specifications produced by the multi-layer screen are discharged from their respective outlets.

It has the advantages of low energy consumption, high output, simple structure, easy maintenance, fully enclosed structure, etc., no dust leakage occurs during the screening process, and automatic discharge is possible, which is very suitable for assembly line operations.

The screen body of the Rectangular vibrating screen can be very large, and its screening accuracy is average, but the screening output is very considerable, which is suitable for the screening operation of coarse materials.


   Structural principle
The vibration source of the rectangular vibrating screen is composed of two vibrating motors. The two motors rotate opposite to each other to form a resultant force to make the materials on the screen surface jump in a straight line from the feed port to the discharge port. The materials smaller than the screen aperture become the things under the screen, and the materials larger than the screen aperture become the things on the screen.
The position of vibration motor can be designed as upper type, side type and lower type according to the actual situation of users.



Product Features
1. It can screen granular materials below 400 mesh, and the screening efficiency can reach more than 96%.
2. The 1-6 layer screen design can screen out 2-7 kinds of materials with different particle sizes at the same time to meet the needs of different customers.
3. Double-motor drive, large excitation force, output of 20 tons/hour, energy consumption can be reduced by 30%.
4. The linear vibrating screen adopts a fully enclosed structure, and there is no dust spillage.
5. Screen replacement is simple and fast, only 3 to 5 minutes, and there are many choices of screen material (nylon, PP mesh).


Common Model


Model
YZ-520
YZ-525
YZ-530
YZ-1020
YZ-1025
YZ-1030
Width * Length(mm)
500*2000
500*2500
500*3000
1000*2000
1000*2500
1000*3000
Material granularity(mm)
0.074-10
0.074-10
0.074-10
0.074-10
0.074-10
0.074-10
Vibration times(times/min)
960
960
960
960
960
960
Screen surface inclination(°)
1-7
1-7
1-7
1-7
1-7
1-7
Amplitude(mm)
3-4.5
3-4.5
3-4.5
3-4.5
3-4.5
3-4.5
Layers
1-6
1-6
1-6
1-6
1-6
1-6
Power(Kw)
2*
(0.4~0.75)
2*
(0.4~0.75)
2*
(0.4~0.75)
2*
(0.4~1.1)
2*
(0.4~1.1)
2*(0.4~1.5)


How to select the right type?
Attention:
The selection of screening equipment and your use of demand has a lot to do with the following information you need to provide.

Ⅰ.If you have ever used the screen machine
Kindly please tell us its DIAMETER,LAYERS,MESH SIZES,MATERIALS.

Ⅱ. If never use the machine until now
Please offer us the info about material as below:
1.the name of the material.
2.Material characteristics (e.g. specific gravity, bulk density, water content, fluidity, adhesion, electrostatic properties, etc.)
3.the purpose of use (sieving / debris / liquid filtration / media separation)
4.How many layers do you need? Mesh size of each layer?
5.expected processing capacity per hour (Kg/h)
In this way,we can precisely choose the matching model for you to meet your use requirements.
6.Voltage(V),Frequency(Hz),Phase(P)






General requirements
Model
520/525/530/1020/1025/1030
Number of Layers(L)
1-6
Main Material
Stainless Steel(304/316L)·Carbon Steel(Q235)·PP
Screen Mesh Number
2-70mesh
Sealing Strip
Silica gel / Rubber







Special requirements
Overall height of the fuselage
Please communicate specifically
Inlet
Angle / Size and so on
Outlet
Angle / Size /Add valve
Observation port
Silicone cover / Rubber cover / Glass cover
spring
You can choose whether to add a silicone protective cover
Internal spray(mm)
PTFE / ePTFE / WC / Al2O3
Equipment surface treatment
Polishing / Sandblasting
Body metal material requirements
For example: require no Cu and Zn (except electrical parts)
Vibration motor
Ordinary motor / Explosion-proof motor
other


Show Details


Spring
Use high-quality steel springs, can add silicone protective cover as needed.
Vibrating Motor
Using stable vibration motor, explosion-proof motor can be selected according to needs.
Screen
You can choose to weave a screen or a punching plate according to your needs. The screen frame is available in wood and steel.


Welding technology
Sophisticated welding process is the guarantee of quality.
Feet
The feet can be selected to move the pulley according to the needs.
Vent
Some application scenarios may require a vent with a filter device.


Product Show
We provide you with quality products and services.






---------------------------------------------------------------------------------------------------------
Please click on the pictures below to learn about related products





Application


Application Scenario Description
Rectangular vibrating screen is a common screening equipment, commonly used to screen granular and relatively coarse powder materials, with high output and good durability.

Common screening materials are:
Food industry: sesame, peanuts, soybeans, wheat bran, corn, spices, salt, starch, etc.
Pharmaceutical industry: Chinese medicine powder, pellets, pellets, etc.
Chemical industry: urea, fertilizer, coke, activated carbon, etc.
Metallurgical industry: refractory materials, high territory, lime, alumina, quartz sand, lead powder, aluminum powder, etc.
Other industries: plastic particles, abrasives, additives, activated carbon, etc.
