OEM DC 12000BTU inverter r410a wall mounted split type air conditioner
OEM DC 12000BTU inverter r410a wall mounted split type air conditioner
OEM DC 12000BTU inverter r410a wall mounted split type air conditioner
OEM DC 12000BTU inverter r410a wall mounted split type air conditioner
OEM DC 12000BTU inverter r410a wall mounted split type air conditioner
OEM DC 12000BTU inverter r410a wall mounted split type air conditioner

OEM DC 12000BTU inverter r410a wall mounted split type air conditioner

Share on (1600434995535):


Price:$235.79 - $263.53

Quantity:


Product Overview

Description





Specification


Model
YS-12HRN1
Power supply
Ph-V-Hz
220-240V- 50Hz, 1Ph
Cooling
Capacity
Btu/h
12000
Input
W
1095
Rated current
A
4.8
EER
W/W
3.21
Heating
Capacity
Btu/h
13000
Input
W
1055
Rated current
A
4.6
COP
W/W
3.61
Max. input consumption
W
1650
Max. current
A
8.0
Starting current
A
/
Compressor
Model
ASM140V1VFT
Type
ROTARY
Brand
GMCC
Capacity
Btu/h
13853/13853
Input
W
955/995
Rated current(RLA)
A
4.35/4.2
Locked rotor Amp(LRA)
A
25
Thermal protector
/
Thermal protector position
INTERNAL
Capacitor
uF
35
Refrigerant oil/oil charge
ml
ESTER OIL VG74/350
Indoor fan motor
Model
YKFG-13-4-38L / RPG13H
Input
W
40
Capacitor
uF
1.2
Speed(Hi/Mi/Lo)
r/min
1150/950/800
Indoor coil
a.Number of rows
2
b.Tube pitch(a)x row pitch(b)
mm
19.5x11.6
c.Fin spacing
mm
1.2
d.Fin type (code)
Hydrophilic aluminium
e.Tube outside dia.and type
mm
Φ5,innergroove tube
f.Coil length x height x width
mm
595x273x23.2
g.Number of circuits
4
Indoor air flow (Hi/Mi/Lo)
m3/h
568/440/352
Indoor noise level (Hi/Mi/Lo)
dB(A)
41/36/31
Indoor unit
Dimension(W*D*H)
mm
805x194x285
Packing (W*D*H)
mm
870x270x360
Net/Gross weight
Kg
7.7/10.0
Outdoor fan motor
Model
YKT-32-6-203L
Input
W
72.5
Capacitor
uF
2.5
Speed
r/min
850/770
Outdoor coil
a.Number of rows
1
b.Tube pitch(a)x row pitch(b)
mm
21×22
c.Fin spacing
mm
1.2
d.Fin type (code)
Hydrophilic aluminium
e.Tube outside dia.and type
mm
Φ7,innergroove tube
f.Coil length x height x width
mm
744x504x22
g.Number of circuits
2
Outdoor noise level
dB(A)
56
Outdoor unit
Dimension(W*D*H)
mm
770x300x555
Packing (W*D*H)
mm
900x345x585
带管Packing (W*D*H)
910x380x605
Net/Gross weight
Kg
30/32.3
Refrigerant type
g
R410A/740g
Design pressure
MPa
4.2/1.5
Refrigerant piping
Liquid side/ Gas side
mm(inch)
Φ6.35/Φ12.7(1/4"/1/2")
Max. refrigerant pipe length
m
20
Max. difference in level
m
8
Connection wiring
3x1.5+2x0.75(Optional)
Plug type
3x1.5 / VDE
Thermostat type
Remote Control
Operation temperature
℃
17-30
Room temperature
Indoor(cooling/ heating)
℃
17-32/0-30
Outdoor(cooling/heating)
℃
18-43/-7-24
Application area (Cooling Standard)
m2
16-22
Qty’per 20’ /40’ /40'HQ
102/224/255
