Battle Axe Used 3D Wheel Alignment Equipment machine With Freely spare parts calmps model 3D 718X






Product Description








































Adjust camera beam up and down through remote controller, Camera beam Length:2782mm
Column lift height: 1450-2110
32''TV show Measuring data & Parking Turntable Function
with static measuring,Turn Wheels & Static Alignment measuring function
2pcs 5 Mega pixel camera
One interface show all parameters of front wheel and rear wheel(Toe,Camber,castor etc)
with Track width and Wheelbase measuring interface also
Calibration data Saved inside of Camera instead of Software
No need to Re-calibartion even Exchange Camera Inside Processor
With Parking Camera Function




Camera Beam Whole Length 2782mm, With 2pcs 5 Mega Pixel Industrial Cameras


3D camera beam





Camera Beam Adjusted up and Down through Remote Controller


3D alignment machine Remote Controller.jpg





with 3 Alignment Mode:Push Vehicle Alignment, Static alignment and Rotate Target Plate Alignment


Wheel Alignment Software 3 mode.jpg





3D-718S Wheel Alignment Software -With Vehicle Diameter Measuring Function including Track Width and Wheelbase Measuring 3D wheel alignment software vehicle diameter.jpg


3D-718S Wheel Alignment Software -All Parameters showed in one Interface including toe, camber, caster etc..


3D wheel alignment software all angle in one page.jpg





3D-718S Wheel Alignment Target Plate: 5 years Warranty made by Korea ABS Material ..Very Hard ..Kindly Visit Battle-Axe homepage and Watch the Vedio


wheel alignment Target Plate.jpg





3D-718S Wheel Alignment Technique Data
















































































Parameter



Precise



Resolution



Test Range



Total testing Range



Total toe



±2′(±0.03º)



0.6′( 0.01º)



±20º



±30º



Individual toe



±2′(±0.03º)



0.6′( 0.01º)



±10º



±20º



Camber



±2′(±0.03º)



0.6′( 0.01º)



±10º



±10º



Castor



±4′(±0.06º)



0.6′(0.01º)



±20º



±30º



SAI / KPI



±4′(±0.06º)



0.6′(0.01º)



±20º



±30º



Setback



±2′(±0.03º)



0.6′(0.01º)



±10º



±20º



Thrust angle



±2′(±0.03º)



0.6′( 0.01º)



±10º



±20º



Wheelbase difference



±2′(±0.03º)



0.6′(0.01º)



±10º



±20º



Track width difference



±2′(±0.03º)



0.6′(0.01º)



±10º



±20º



Wheel size working range



13′′-24′′







Packaging & Shipping


 package






















ItemPackage SizeN.G/W
camera beam3050x400x430MM-1pcs20/31.5kgs
cabinet900x600x1300mm-1pcs135/169.5kgs

3D-718S Wheel Alignment Overall Size


708 Dimension



Our Services


 -Warranty Period: within 12 months From Bill of loading date not including PC Unit including computer hard disk, LCD and Printer


-Computer, Printer and TV from China original, kindly check your local service center, or you can order our wheel aligner machine without computer,printer and LCD.. buy from local in order to get after service


-Computer Brand we used HP, Printer is Canon and TV Set from Haier (we will not give futher notify if we change brand)


-Easy spare parts like USB power line, insurance tube we will sent together with whole machine for future replacement, for other spare parts belongs to chargeble Range if replacement, Express cost beared by Buyer


-if the Parts can be Repair, we will not charge cost for Repair, but come and back Express cost on Buyer side


-Insurance will not covered with any Shipment Except for buyer Special Mentioned


-Generally Clear customs Documents we only supply Bill of loading, packing list and Commercial Invoice, if any special documents need like CO kindly Inform us in advance, otherwise we will not responsible for loose during clear customs





Company Information


BATTLE-AXE is the leading manufacturer of tyre service equipment in China, specializing in Dynamic 3D Wheel Alignment System, CCD wheel alignment, Scissor Tyre Lifting Equipment, and Pneumatic Car Jack Since 2002, Located in Zhongshan City Guangdong Province China Not Far From Hongkong & Macau..Nearest Sea Port is Guangzhou and Shenzhen




Milestones



  • CCD wheel Wheel alignment production in 2003

  • Gained wheel Remote Control for CCD Alignment Patent in 2004

  • Massive production of Lift Equipment in 2005

  • Invention of the Real Dynamic Scanning 3D Alignment Technology in 2006

  • Invention of Pneumatic Car Jack in 2008

  • Be the First and Only Chinese Brand being OEM Equipment Provider for Continental Tyre Group China in 2012

  • New 3000 SQM modern factory set up in Zhongshan, Canton in 2013

  • Be the First and Only Chinese Brand Being OEM Supplier For Tech China since 2014
