Factory price plastic granules making machine plastic granulator machine

Factory price plastic granules making machine plastic granulator machine

Category: Plastic Granulators >>>
Supplier: Tianhua,Institute,of,Chemical,Machinery,and,Automation,Co.,Ltd.

Price:

Price in USD:Details

Quantity:

Product Overview

Description

Product Description

Water-cooling strand pelletizing line consists of stainless steel water tank for cooling and strand pelletizer for PE, PVC, PA, PP, PS, PET and ABS cutting. Strand pelletizing is widely applied pelletizing process suitable for almost all materials. This process features simple equipment structure and convenient operation and maintenance. When pelletizing is performed in cold condition, pellets sticking can be avoided. This water-cooling strand pelletizing line (water-cooling strand pelletizer) adopts parallel twin screw, which is specially designed for waste PET processing. The pelletizer line can adopt different palletizing methods according to different moulds, such as strand type pelletizer, water ring pelletizer and underwater pelletizer. The most common pelletizing method for compounding is strand pelletizer. The water-cooling strand pelletizing line offers a larger feed opening allowing for increased output.

Main Features:
1. Strand pelletizer is made up of high quality stainless steel, which is sharp and hard-wearing.
2. The working speed of the water-cooling strand pelletizing line is adjustable.
3. It is easy to clean and it can be operated with no noise.
4. Strand pelletizer is mainly suitable for PE high and low pressure polyethylene plastic waste film, leftover material, defective goods, as well as raw materials.
5. Water-cooling strand pelletizing line possesses stable and high output.

Technical Parameters of Strand Pelletizer:

1. Specifications of Cantilever Pelletizer

Model	Capacity	Max. Strand Number	Line Speed	Pellet Size	Rated Torque	Rubber Roller Size	Rotary D×L	Blade Number	Fixed Knife L × W × H	Power
Model	kg/hr		m/min	mm	N. m	mm	mm			kw
SP-25	25	2	42	φ 3 × 3	4.9	Φ 60 × 50	Φ 90 × 50	14	50 × 8 × 20	0.75
SP-60	60	4	42	φ 3 × 3	7.1	Φ 90 × 70	Φ 120 × 96	14	96 × 15 × 15	1.1
SP-100	100	6	42	φ 3 × 3	9.7	Φ 90 × 70	Φ 120 × 96	14	96 × 15 × 15	1.5
SP-200	200	12	72	φ 3 × 3	19.2	Φ 100 × 100	Φ 160 × 100	24	100 × 15 × 30	3
SP-300	300	15	96	φ 3 × 3	19.2	Φ 120 × 100	Φ 200 × 100	32	100 × 15 × 30	3
SP-400	400	25		φ 3 × 3	25.2					4.0
SP-500	500	25	96	φ 3 × 3	36.1	Φ 120 × 200	Φ 200 × 200	32	200 × 15 × 30	5.5
SP-600	600	32		φ 3 × 3	47.7					7.5
SP-900	900	42		φ 3 × 3	69					11.0

2. Specifications of Gantry Pelletizer

Model	Capacity	Max Strand Number	Line Speed	Pellet Size	Rated Torque	Rubber Roller Size	Rotary D × L	Blade Number	Fixed Knife L × W × H	Power
SP	kg/hr		m/min	mm	N. m	mm	mm			kw
SP-25	25	2		φ 3 × 3	4.9					0.75
SP-60	60	4		φ 3 × 3	7.1					1.1
SP-100	100	6		φ 3 × 3	9.7					1.5
SP-200	200	12		φ 3 × 3	19.2					3
SP-300	300	15	72	φ 3 × 3	19.2	Φ 100 × 150	Φ 160 × 150	24	150 × 15 × 30	3
SP-400	400	25	72	φ 3 × 3	25.2	Φ 100 × 200	Φ 160 × 200	24	200 × 15 × 30	4.0
SP-500	500	25	96	φ 3 × 3	36.1	Φ 100 × 200	Φ 200 × 200	32	200 × 15 × 30	5.5
SP-600	600	32	96	φ 3 × 3	47.7	Φ 100 × 200	Φ 200 × 200	32	200 × 15 × 30	7.5
SP-900	900	42	96	φ 3 × 3	69	Φ 100 × 300	Φ 200 × 300	32	300 × 15 × 30	11.0

Lantai Plastics Machinery is a professional manufacturer of water-cooling strand pelletizing lines in China. In addition to this strand pelletizer, we also specialize in producing twin screw extruder, screw feeder, electronic control system, some auxiliary equipment, and so on. With reliable quality control system, our products have passed CE and ISO9000 certification. Our water-cooling strand pelletizing lines are exported to the United States, Germany, Japan, Denmark, Poland, Turkey, Morocco, Russia, India, Malaysia, Indonesia, Vietnam, Thailand and many other countries.
