NRF24l01 2.4GHz Wireless Module Mini Version Power Enhanced Version SMD
- Category: >>>
- Supplier: BeFunS Intelligent (ShenZhen) Co. Ltd.
Share on (1600437151608):
Product Overview
Description
About this item
NRF24L01 + wireless module 2Mbit / s 1Mbit / s 250Kbit / s transfer rate options MultiCeiver hardware to provide the 6 receiver functions at the same time + / - 60 ppm crystal Only need an external inductance when match antenna No multi-layer PCB 5V input tolerance level No need external level converter Improved ShockBurst and serial interface can be easily connected with a variety of low-cost MCU No MCU with SPI Interface 20 pin 4x4mm QFN leadless package very few external components The 2Mbit / s rate when the peak current 12.5mA received The 2Mbit / s rate @ 0dBm output current of 11mA peak 2Mbit / s rate of only a small average current 400nA Power-down mode, power consumption Power consumption of 32uA in standby mode 130us fast switching and wake-up time With on-chip voltage regulator oltage regulators In the 1.9 to 3.6V low voltage operation Possible to reduce noise Application:Mouse, keyboard, wireless headsets, intelligent sports equipment, remote controls, voice applications, security devices, VOIP applications.
Features |
Product Description
* NRF24L01 is a monolithic transceiver chip working in the ISM frequency band of 2.4-2.5GHz.
* The wireless transceiver includes: frequency generator enhanced SchockBurstTM mode controller power amplifier crystal amplifier modulator demodulator output power channel selection and protocol setting can be set through SPI interface.
* The current consumption is 9.0mA when the transmission power is 6dBm in the transmission mode, 12.3mA in the acceptance mode and lower in the standby mode.
* The ISM frequency band is open, which has a large transmission power of 0dBm and is free of license. Support six channels of data reception.
Our Advantages
BeFuns Intelligence (Shen Zhen) Ltd.
1、We have a strong R&D team, including hardware engineers, software engineers, algorithm engineers, 3D structure engineers.
2、We have several fully automatic production lines, production equipment including high-speed placement machine, reflow machine, wave soldering machine, 3D scanner, visual inspection machine, laser marking machine.
3、We can support product customization, quick response and fast delivery.
2、We have several fully automatic production lines, production equipment including high-speed placement machine, reflow machine, wave soldering machine, 3D scanner, visual inspection machine, laser marking machine.
3、We can support product customization, quick response and fast delivery.
Certifications
Why Choose Us
FAQ
Q1: Are you manufacturer ?
A1: Yes, we are manufacturer.
A1: Yes, we are manufacturer.
Q2: Do you accept OEM design?
A2: Yes,we do.We can design according to your requirement, MOQ usually >1000.
A2: Yes,we do.We can design according to your requirement, MOQ usually >1000.
Q3: How long is your delivery time?
A3: Normally 3-6 working days after payment; Special requirement orders, delivery time is negotiable.
Q4: How can we get samples from you ?
A4: Samples are available. Normally we take 2 days to arrange samples. If we have no business record with you before, we need to charge boot samples cost and post courier freight.
Q5: Do you accept pay 30% in advance?
A5: Yes,we do.We can start to prepare your goods when receive 30% payment, and send them after get the rest 70% payment.
Q6: What payment terms you accept?
A6: We accept Paypal, T/T, Alibaba Trade Assuarce, Western Union, Wechat, Alipay, in Cash (RMB or USD)..
