JRC MUSES JRC MUSES Series 2 channel electronic volume low noise and low distortion MUSES72323V TE1
- Category: >>>
- Supplier: Shenzhen Pawpaw Electronic Technology Co. Ltd.
Share on (1600437177537):
Product Overview
Description
Products Description
JRC MUSES JRC MUSES Series 2-channel electronic volume low noise and low distortion MUSES72323V-TE1
Model Munber | MUSES72323V-TE1 |
Description | MUSES |
Type | Electronic Volume |
Operating Voltage | Analog ±10 to ±18V Digital +3.0 to +5.5V |
3-Wired Serial Control | Chip Address Select Function |
Selectable 8-Chip Address | Available for using eight chips on same serial bus line |
Low Output Noise | *It conforms to the characteristic of an external operational amplifier. |
Low Distortion | *It conforms to the characteristic of an external operational amplifier. |
Volume | 0 to -111.75dB /0.25dB step +21 to 0dB /3dB step, Mute |
Package Outline | SSOP32 |
Package | 100/pack |
Application
MUSES01 is JRC's high-end operational amplifier MUSES series, pursuing high-quality and high-definition analog signals, PawpawElectronics recommends using MUSES01 for the following equipment:
HiFi player
The MUSES72323 is a ±18V operation high quality audio volume. It provides low output noise and low distortion characteristics, 0.25dB step volume. In addition, employing external op-amps as output signal buffers, it offers designer’s variety of circuit design.
All of functions are controlled via three-wired serial bus. Selectable chip address is available for using two chips on same serial bus line.
The MUSES72323 is suitable for High-end audio equipment and professional audio equipment.
