  • RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104
RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104

RF Coaxial connector rf connector sma right angle jack pcb mount for harting 9030006104

Share on (1600437361098):


Price:$0.45 - $0.60

Quantity:


Product Overview

Description



Customized Your Requested Part Number
Please code according to the specifications you need.
It is more convenient to make inquiries by code




Contact Resistance:
20M Ω Max
Insulation Resistance:
1000M Ω Min
Contact Material:
Brass gold flash
Insulation Material:
Telflon
Contact Plating:
Gold flash
Body Material:
Phosphor Bronze
Withstand Voltage:
250V AC/DC
Operating Temperature:
-55°C to +125°C
Relative  Humidity:
Max 95% (40℃± 2 ℃）
Impedance:
50 ohm
Manufacturer Standard Lead Time:
1-3 Weeks
