Product Overview
Description
Product Description
The basic performance parameters
1, Capacity: 0.1-0.5KG / hr
2, Screw rotation speed: max to 15r/min
3, The production line center height: 300mm;
5, Line direction: left and right to close the discharge →
6, The installation area: length×width*height = 0.75m * 0.2m * 0.5m ; weight: about 30KG
7. Motor Power: 250W
8. Voltage: 220V 110V, or customers can specify
1, Capacity: 0.1-0.5KG / hr
2, Screw rotation speed: max to 15r/min
3, The production line center height: 300mm;
5, Line direction: left and right to close the discharge →
6, The installation area: length×width*height = 0.75m * 0.2m * 0.5m ; weight: about 30KG
7. Motor Power: 250W
8. Voltage: 220V 110V, or customers can specify
Technical Parameters
Model | SJ-15 |
Production Capacity | 0.1-0.5 (kg/h) |
Raw Material | PE/PP/PVC/ PLA/PC/TPU/ABS/NYNONG |
Voltage | Single phase, 220V 60Hz |
Main Motor Power | 250W |
Heating Power | 1000W |
Screw | Single Screw Extruder |
Diameter | 15mm |
Screw L/D | 12: 1 |
Material | 38CrMoAlA |
Surface treatment | Nitrogenization and polished |
Inner surface treatment | Nitrogenization and polished |
Max heating temperature | 300℃ |
The nitride layer thickness | 0.5~0.7 mm. |
The surface hardness | HV850~940 |
Extruder total Power | 940W |
Control Type | Single phase electronic speed governor control |
Heating control zone | 3 |
