Product Overview

Description

Biomass gasifier burner

Industrial Waste Wood Burners



Biomass gasifier burner is a ideal high temperature burner for variety of industrial heating and drying process, and it’s the best option to replace Oil/Gas/Electricity burner machines to save 30-70% of the fuel cost.

Biomass gasifier burner is a heat energy equipment for the R&D of variety of biomass fuel characteristics and mature application, designed by Foshan GreenVinci biomass Machinery Co., Ltd. With applicable to a variety of biomass fuel, high degree of automation, ash free, stable operation, high thermal efficiency, operation & maintenance convenience, is the only biomass combustion equipment can completely replace the diesel, gas burner in the market. It is energy saving, environmental friendly and less emissions, make the vast number of users satisfied!



Parameter of biomass gasifier
Manual discharge
Item No.	GV-240-G	GV-360-G	GV-480-G	GV-600-G
Output Power(Kcal)	240×104	360×104	480×104	600×104
Applicable Fuel	wood chips,pellet
Voltage	380V	380V	380V	380V
Feeding system	Pneumatic	Pneumatic	Pneumatic	Pneumatic
Cleaning way	Manual/Auto	Manual/Auto	Manual/Auto	Manual/Auto
Power Consumption	9.25KW	17KW	21.5KW	29.5KW
Fuel consumption(h)	600kg/h	900kg/h	1200kg/h	1500kg/h
Size	2396*2800*3158mm	3103*2340*3354mm	3303*2340*3354mm	3703*2340*3654mm
Gross weight	5000kg	10200kg	10600kg	13600kg
Nozzle from ground floor	1252mm	1416mm	1436mm	1446mm
Nozzles dia	560mm	596mm	636mm	676mm
Nozzle material	310s/316
Control system	Frequency conversion, automatic constant temperature, touch screen box
Gasification furnace	High temperature - resistant corundum cement in one pouring molding
Feeding system	belt conveyor
