MAGNATE BATTERY ER14335 LiSOCl2 Battery Cell 2/3AA Size 3.6v 1600mah
- Category: >>>
- Supplier: Shenzhen Magnate New Energy Limited
Share on (1600438142833):
Product Overview
Description
Product Description
Hot Sale Safe Low Self-Discharge Rate Alternative Battery
2/3AA Size ER14335 Cylindrical Battery Cell 3.6V
MAGNATE Lithium Battery replace TL-4955
1. ER14335 battery or battery packs
2. Low Self-Discharge Rate
3. Wide Working Temperature Range -55~+85
4. UL, UN38.3, CE,
ER14335 Primary Lithium Battery bobbin type 2/3AA Size can replace TL-4930 TL-5930 TL-2200 LS33600 XL-205F SB-D01 XL-200F
Specifications:
| Model No. | Size | Max Dimensions (mm) | Weight(g) | Norminal Voltage (v) | Norminal Capacity (mAh) | Max Continuous Current (mA) | Max Pulse Current (mA) | Operating Temperature (°C) | End Voltage (v) |
ER14335 |
2/3AA |
14.5X33.5mm |
100 |
3.6 |
1600mAh |
50 |
120 |
-55~+85 |
2.0 |
Product Application
Main applications:
1. Utility meter (water, electricity, gas, heat meter)
2. Automatic meter reading
3. Alarm or security system (smoke alarm detector)
4. GPS tracking systems(data logger, dog collar, PIR sensor)
5. Real time clock
6. Smart meters
7. Automotive electronics
8. Professional electronics
Advantage:
1. High and stable operating voltage
2. Low self-discharge rate (less than 1% per year of storage at +25°C)
3. Wide range of operating temperature
4. Stainless steel container and end caps
5. Hermetic glass-to-metal sealing
6. Non-flammable electrolyte
7. Compliant with IEC86-4 safety standard, UL, CE, UN.
Main Products
Related products:
| Model | Size | Norminal Voltage (V) | Norminal Capacity (mAh) |
| ER14250 | 1/2AA | 3.6 | 1200 |
| ER14250M | 1/2AA | 3.6 | 800 |
| ER14505 | AA | 3.6 | 2400-2700 |
| ER14505M | AA | 3.6 | 2200 |
| ER14335 | 2/3AA | 3.6 | 1650 |
| ER14335M | 2/3AA | 3.6 | 1350 |
| ER17505 | A | 3.6 | 3400 |
| ER17505M | A | 3.6 | 2800 |
| ER17335 | 2/3A | 3.6 | 1900 |
| ER17335M | 2/3A | 3.6 | 1700 |
| ER18505 | - | 3.6 | 3800 |
| ER18505M | - | 3.6 | 3500 |
| ER26500 | C | 3.6 | 9000 |
| ER26500M | C | 3.6 | 6000 |
| ER34615 | D | 3.6 | 19000 |
| ER34615M | D | 3.6 | 14000 |
| ER251020/ER261020 | CC | 3.6 | 15000 |
| ER341245 | DD | 3.6 | 38000 |
| ER9V/CP9V/CR9V | - | 9 | 1200 |
| CR14250 | 1/2AA | 3.0 | 650 |
| CR123A/CR17335 | 2/3A | 3.0 | 1350 |
| CR17450 | AG | 3.0 | 2200 |
| CP505050 | - | 3.0 |
