8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen
8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen
8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen
8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen
8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen

8 inch customized 800*1280 31 pin IPS DSI MIPI 4L interface ILI9881C tft display lcd module screen

Share on (1600438275972):


Price:$0.10

Quantity:


Product Overview

Description









Product Discription


name
8 inch lcd display
model
FPC_XMZ080B009A2(ILI9881C with BOE N
size
8 inch
resolution
800x1280
display type
TFT
display color
16.7M
Pixel Pitch
0.04485 (H) x 0.13455 (V)
viewing direction
ALL
controller IC
ILI9881C
diasplay mode
Transmissive /Normally Black
overall size
114.60*184.10*2.7 mm
active area
107.64*172.22mm
luminance
500 cd/m2、 300cd/m2
contrast
500:1
interface type
DSI MIPI 4L
pin No.
31
backlight type and color
LED backlight / White
backlight
24LED Vled=9V Iled=160 mA
life span
50,000 hours
operating temperature
-20℃~70℃
storating temperature
-30℃~80℃
compliant
RoHs
certification
ISO:9001:2008
input voltage
3.0 v
