Split Core Current Transformer 100A/33.3mA Xh Sct T16 Hot Sales Current Transformer

Product Overview

Description

Split core current transformer with high quality and CE UL certification

Specifications:
Maximum continuous primary current 100A
Secondary turns: 33.3mA

current transformer output: voltage or mA
Wire leads: 24# AWG UL2464 24AWG
Frequency: 50/60Hz

Accuracy: 1%

DC resistance: 460ohms @ 20degree Celsius

Applications:
Portable instruments
Sub-metering
Monitor motor load



Model	I.D.	Ratio	Rated Amps	Accuracy
XH-SCT-T10	10mm	3000:1	5, 15, 30, 50, 75,80	1.0
XH-SCT-T16	16mm	3000:1	50, 70, 100, 120	1.0
XH-SCT-T24	24mm	3000:1	100, 150, 200, 300	0.5 , 1.0
XH-SCT-T36	36mm	3000:1	300, 400, 500, 600	0.5 , 1.0
