Product Overview
Description
Product description
Model No. | Stainless Edible Oil Refining Equipment | ||||||
Daily Output | 750 kg | ||||||
Size | 3840*900*2140 | ||||||
Advantage | High efficiency, energy saving and super long warranty | ||||||
Application | It is widely used in chemical, oil, petroleum, coating, food, pharmaceutical and other industries. | ||||||
The small edible oil refinery is made up of refining tank, decolorizing tank, oil pump, hot water tank and electric cabinet together with the auto temperature control set, thermal insulation device and feeding buffer sets, with them it could achieve the purpose of degumming, deacidification, dehydration and decolorizing for crude oil.
It is more suitable for a small capacity cooking oil production plant, it can refine sunflower seeds oil, cottonseeds oil, peanut oil, soybean oil, palm oil, palm kernel oil, olive oil, flaxseed oil, mustard oil, etc.
Smaller investment, easier operation.
The refiner machine’s producing capacity: refining tank 200-250kg/tank, decolorizing tank filtering efficiency 4-5H/tank.
The working period is effected by both the quality of crude oil and the required grade of refined oil. If the crude oil quality is good, it needs about 4 hours to reach oil grade 3 or 4 through heating, hydrating, settling, and dewatering processing steps.
It is more suitable for a small capacity cooking oil production plant, it can refine sunflower seeds oil, cottonseeds oil, peanut oil, soybean oil, palm oil, palm kernel oil, olive oil, flaxseed oil, mustard oil, etc.
Smaller investment, easier operation.
The refiner machine’s producing capacity: refining tank 200-250kg/tank, decolorizing tank filtering efficiency 4-5H/tank.
The working period is effected by both the quality of crude oil and the required grade of refined oil. If the crude oil quality is good, it needs about 4 hours to reach oil grade 3 or 4 through heating, hydrating, settling, and dewatering processing steps.
Details Images
Company profile
Customer
FAQ
Q: Why work with your company ?
A: We have 14 years experience in oil press machine industry, and we can help you find a great solution that can save your cost and reach your production targets. Our main products including :screw oil press, oil filter, oil refinery machine and spare parts etc.
Q: How can I judge your machine quality ?
A: Actually we already got good reputations in Russia and The Five Countries in Central Asia because of our service and stable quality. All of our machines can provide 1 year warranty and lifetime maintenance, for core parts are 6 months warranty.
Q: If i don't know how to operate this machine ? How can i do ?
A: Our engineer will help you from the starts, and machine has been tested and fully assembled before shipping, you just needs to make 2-4 hours wear-in and then can work.
Q: What's wear-in for new machine?
A: Using 10 KG oil cake + 1 KG sand + 1 KG water, mix them, put in oil press, wear in 3~4 hours.
1. 1st hour, adjust oil cake thickness as 3 mm.
2. 2nd hour, adjust oil cake thickness as 2.5 mm.
3. 3rd hour, adjust oil cake thickness as 2 mm.
Q:What are cold press and hot press?
A: Cold press is pressing dry and raw seeds. usually need to press 2 times to get maximum oil.
Hot press is pressing roasted seeds. usually only 1 time to get maximum oil. peanuts roast to 125~130 degree with 1~2% moisture.
Q:What service do you provide?
A: (1) 1 year free warranty, whole lifetime maintenance.
(2) Supplying wearing parts all year around.
(3) Supplying technical solutions at any time.
(4) Helping design and plan the oil plants construction.
(5) Providing installation video.
(6) Developing agents with good policies around world.
Q: How can I get a quotation?
A: Contact us immediately for further details by sending us an inquiry.
A: We have 14 years experience in oil press machine industry, and we can help you find a great solution that can save your cost and reach your production targets. Our main products including :screw oil press, oil filter, oil refinery machine and spare parts etc.
Q: How can I judge your machine quality ?
A: Actually we already got good reputations in Russia and The Five Countries in Central Asia because of our service and stable quality. All of our machines can provide 1 year warranty and lifetime maintenance, for core parts are 6 months warranty.
Q: If i don't know how to operate this machine ? How can i do ?
A: Our engineer will help you from the starts, and machine has been tested and fully assembled before shipping, you just needs to make 2-4 hours wear-in and then can work.
Q: What's wear-in for new machine?
A: Using 10 KG oil cake + 1 KG sand + 1 KG water, mix them, put in oil press, wear in 3~4 hours.
1. 1st hour, adjust oil cake thickness as 3 mm.
2. 2nd hour, adjust oil cake thickness as 2.5 mm.
3. 3rd hour, adjust oil cake thickness as 2 mm.
Q:What are cold press and hot press?
A: Cold press is pressing dry and raw seeds. usually need to press 2 times to get maximum oil.
Hot press is pressing roasted seeds. usually only 1 time to get maximum oil. peanuts roast to 125~130 degree with 1~2% moisture.
Q:What service do you provide?
A: (1) 1 year free warranty, whole lifetime maintenance.
(2) Supplying wearing parts all year around.
(3) Supplying technical solutions at any time.
(4) Helping design and plan the oil plants construction.
(5) Providing installation video.
(6) Developing agents with good policies around world.
Q: How can I get a quotation?
A: Contact us immediately for further details by sending us an inquiry.
