Hot Sale Automatic Cartoning Production Lines Packing Equipment Vertical Packaging Machine
- Category: >>>
- Supplier: Zhejiang Haichen Machinery Co. Ltd.
Share on (1600439124699):
Product Overview
Description
Products Description
Blister making machine | Cutting frequency | 16～30 times/min | |||
Maximum forming area | 220×350 mm | ||||
Travel distance | 50 ～220 mm | ||||
Tablet plate specification | At clients' request | ||||
Packing material | Non-toxic hard PVC film(conform to GB5663) | ||||
0.15～0.5×350mm， | |||||
Winding axle diameter is 75mm | |||||
Electric heating power | PVC preheating plate 2×4.5 KW | ||||
Mould tool cooling | 13-15° recycling water≥ 60 L/h | ||||
Main motor power | 2.2KW | ||||
Cartoning packaging machine | Box specification (length*width*height) | （65～210）×（35～90）×（16～70）mm | |||
Box paper specification | white cardboard 300~350g/m2 | ||||
Tablet instruction sheet size(Length*width) | （90～260）×(100～190）mm | ||||
Tablet instruction sheet specificatioin | 60-75g/m2（printing papaer） | ||||
Cartoning capacity | 80boxes/min(10pcs/box) | ||||
Main motor power | 1.5KW | ||||
Power supply | 380V Three phase four line 50Hz | ||||
Air pump | Volume | ＞0.2 m3 | |||
Air pressure | 0.6~0.8MPa | ||||
The whole production line (length*width*height) | 8500×2700×1800mm | ||||
Total weight | 9000 kg | ||||
Total power | 23KW | ||||
Total Air consumption (Max) | 480 L/min | ||||
