| Model Number | ALF80G222FP400 |
| Type | Aluminum Electrolytic Capacitor |
| Place of Origin | China |
| Brand Name | Original |
| D/C | Newest |
| Supplier Type | Agency |
| Capacitance | 2200 uF |
| Cross Reference | - |
| Media Available | datasheet |
| Tolerance | ±20% |
| Package Type | Through Hole, Press-Fit |
| Rated Voltage | 400 V |
| Operating Temperature | -40°C ~ 105°C |
| Brand | CAP ALUM 2200UF 20% 400V SNAP |
| Specification | - |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 60mOhm @ 100Hz |
| Applications | General Purpose |
| Impedance | 32 mOhms |
| Application | General Purpose |
| Package / Case | Radial, Can - Press-Fit - 5 Lead |
| Surface Mount Land Size | - |
| Height - Seated (Max) | 4.213 (107.00mm) |
| Size / Dimension | 1.772 Dia (45.00mm) |
| Lead Spacing | 0.984 (25.00mm) |
| Series | ALF80 |
| Lifetime @ Temp | 9000 Hrs @ 105°C |
| Polarization | Polar |
| Ratings | - |
| Warranty | One Year |
| Sample | Available |
| Part Status | In Stock |
| Ripple Current @ Low Frequency | 7.24 A @ 100 Hz |
| Ripple Current @ High Frequency | 16.09 A @ 10 kHz |
| Package | Bulk |
