1200 degree Industrial three zones quartz tube furnace with vacuum pump
- Category: >>>
- Supplier: Henan Gurdoo Industry Co. Ltd.
Share on (1600439606368):
Product Overview
Description
Product Description
1200 degree Industrial three zones quartz tube furnace with vacuum pump
Technical data of quartz tube furnace | ||
1. Excellent temperature uniformity | 10~150mm | |
2. PID Programmable Temperature Controller | 2500mm | |
3. 30 programmable segments | ||
4. High-quality heating elements | 5~100mm | |
5. High energy efficiency | 2500mm | |
6. Safety interlock system | ||
7. Overheat protection | ||
8. Power failure protection | ||
Application
Three zones quartz tube furnace is widely used in the laboratory and manufacture of the field of pottery, chemical industry, metallurgy, and glass industries, new material developing, machinery, fire-proof material, architecture, special material and etc.
Detailed Images
Our furnaces contain muffle furnace, laboratory furnace, box furnace, chamber furnace, crucible furnace, atmosphere furnace, bottom (top) Loading furnace, high temperature furnace, sintering furnace, dental furnace, etc;
Tube furnace, double (multi) zones tube furnace, multi-position rotary tube furnace, vertical tube furnace, etc.;
Vacuum furnace, etc.
Tube furnace, double (multi) zones tube furnace, multi-position rotary tube furnace, vertical tube furnace, etc.;
Vacuum furnace, etc.
Size Information
Item | Vacuum tube furnace | ||||||
Max. temperature | 1200℃ (<2hour) | 1400℃ (<2hour) | 1700℃ (<2hour) | ||||
Working temperature | 1100℃ | 1300℃ | 1600℃ | ||||
Temperature settings | Single temperature zone, Dual-zone, three temperature zones | ||||||
Temperature accuracy | ±1℃ | ||||||
Temperature uniformity | ±5℃ over 120mm，±3℃ over 80mm | ||||||
Heating rate | 0-20℃ /min | ||||||
Thermocouple | K type | S type | B type | ||||
Heating element | Heating wire | SiC heating element | MoSi2 heating element | ||||
Vacuum degree | 10Pa by mechanical pump | ||||||
Furnace chamber | polycrystalline alumina ceramic fiber board | ||||||
Furnace structure | Double layer steel casing with dual cooling fan, surface temperature below 60C | ||||||
Working voltage | AC110V, 220V, 240V or 380V, 50HZ or 60HZ | ||||||
Stander chamber size (mm) | 40x300 60x300 80x300 100x300 120x300 150x300 40x450 60x450 80x450 100x450 120x450 150x450 Note: the chamber size can be customized | ||||||
Related Products
Packing&Shipping
Three zones quartz tube furnace is packed in export standard plywood case outside, lined with sponge and foam inside.
The goods will be shipped by air, by sea, by railway or by express delivery/courier like DHL, FedEx, TNT, UPS, EMS and so on.
Company Introduction
Henan Gurdoo Industry Co.,Ltd. is founded by engineers who have more than 20 years’ experience in research and production.
Focusing on professional high temperature working field with 100% quality check and durable testing before shipment.
We have a well team-conscious. Assist you to gain competitive advantages are our major focus.
Focusing on professional high temperature working field with 100% quality check and durable testing before shipment.
We have a well team-conscious. Assist you to gain competitive advantages are our major focus.
After Sales Service
Our advantages
1. Any inquiries will be replied professionally within 24hours.
2. Technical staff available for the technical assistance anytime.
3. Professional customization of furnace and project is offered.
4. Small MOQ, Fast delivery and competitive freight.
5. Also can help to purchase other products if you needed.
2. Technical staff available for the technical assistance anytime.
3. Professional customization of furnace and project is offered.
4. Small MOQ, Fast delivery and competitive freight.
5. Also can help to purchase other products if you needed.
FAQ
Q1. What information should we supply to get a quote?
Please offer the specification of three zones quartz tube furnace, such as type, dimension, working temperature, quantity, application etc.
Q2. How long our order can be finished?
A mass of semi-finished products and standard sizes are available in stock, and 10-30days for bulk production or customized products.
Q3. What do you do on quality control?
For every batch, each step and finished products will be inspected when producing by QC department.
Q4. Can you accept OEM/ODM?
Yes, your goods will be produced exactly according to your drawings.
Please offer the specification of three zones quartz tube furnace, such as type, dimension, working temperature, quantity, application etc.
Q2. How long our order can be finished?
A mass of semi-finished products and standard sizes are available in stock, and 10-30days for bulk production or customized products.
Q3. What do you do on quality control?
For every batch, each step and finished products will be inspected when producing by QC department.
Q4. Can you accept OEM/ODM?
Yes, your goods will be produced exactly according to your drawings.
