The Panel Type USB3.1 Expansion card is used VL820 chipset, it is the world’s first USB3.1 Gen2 Hub controller and it features highly-integrated, application specific design, it support 1x upstream port and 4x downstream ports, all of which support 10Gbps USB3.1 Gen2 operation. The downstream ports can support any combination of SuperSpeed Plus(10Gbps),SuperSpeed(5Gbps),High-Speed(480Mbps), Full-Speed (12Mbps),and Low-Speed(1.5Mbps) ,It is widely used in personal computer ,office computers and etc.

Compliant with Universal Serial Bus 3.1 Specification
SuperSpeed Plus USB(USB3.1 Gen2)
Compliant with Universal Serial Bus 2.0 Specification
USB2.0 Hub Support MTT
Upstream:USB3.1 Type A
Downstream:4 x USB3.1 Type A or 2x USB3.1 Type A& 2x USB3.1 Type C
Support Simultaneous Operation of any Combination of SuperSpeed Plus, SuperSpeed, High-Speed, Full-Speed, and Low-Speed Devices
Supports USB Power Saving Features such as Link Power Management ,UxStates , Selective Suspend, and Function Suspend
Each Port support transmission rate of SuperSpeed Plus(10Gbps),SuperSpeed(5Gbps),High-Speed(480Mbps), Full-Speed (12Mbps),and Low-Speed(1.5Mbps)
Comprehensive USB Battery Charging Support
Supports USB Battery Charging Specification V1.2
Supports for vendor specific charging Mode eg.Apple 2.4A,Samsung,etc.
Support system OS, Windows, Mac OS X, and Various Linux kernels without additional drivers.

Linux , Mac OS X ,WindowsXP/Server 2003/Vista/Win7/server2008/ Win8/Win8.1/ Win10/Win11
One available 19P USB3.1 slot
