clinical analytical instruments Medical Hematology machine blood Fully Automated 3 Part Differential Haematology Analyzer
- Category: Clinical Analytical Instruments >>>
- Supplier: Shenzhen Minder Biomedical Tech Co. Ltd.
Share on (1600441963773):
Product Overview
Description
Product Description
Specification
item | value | |
Type | Blood Analysis SYstem | |
Brand | Mydertek | |
Model | CC-3200 | |
Place of Origin | China | |
Province | Guangdong | |
Instrument classification | Class II | |
Warranty | 1 Year | |
After-sale Service | Online technical support | |
Power Supply | 220V 50HZ | |
Environment Temp | 10°C-30°C | |
Throughput | lest than 60 seconds | |
Parameters | 21 parameters+3 histograms | |
after-sale service | online technical support | |
channels | double channels | |
atmospheric pressure | 70.0kpa-106.0kpa | |
counting modes | whole blood, pre-diluted blood | |
1. Highlights l User-friendly interface 10.4 inch true color TFT LCD & touch screen, more visible Minimize the number of interface layers, pop-up soft keyboard, easy to operate l Internationalization support Possible choice of parameter units. Several languages available, can switch language online l Provide various anemia indications Normocytic and normochromic anemia, Macrocytic and normochromic anemia, Microcytic hypochromic anemia, Microcytic anemia l Provide text of alarm information Text of alarm information is clearer than alarm character provided by traditional 3-part analyzer, such as R1, Rm and Pm l Automatic blank counting Automatically start a blank counting and auto-assessment of the results during start-up process l Automatic re-counting Automatically re-count after unclogging treatment while a counting hole is clogged, avoid re-collecting blood l Wider linearity range & excellent repeatability l Maintenance-free syringe l Built-in patented structure thermal printer. Easy to load paper, and fast print of large size report Paper 80mm wide. Report printing takes only 5 seconds l State-of-the-art technology Sweeping flow technology, Pulse discrimination technology, intelligent floating threshold technology | ||
Open System Medical Hematology machine blood Lab Equipment Fully Automated 3 Part Differential Haematology Analyzer
2. Product Specifications l Measuring Principles Impedance method for cells counting Cyanide free colorimetric method for HGB measurement l Measuring Channels Double channel for counting l Throughput From beginning of a test to completion of the printout: ≤60 Seconds l Counting Modes Whole Blood, Pre-diluted Blood l Sample Volume Whole Blood: ≤14µL Pre-diluted Blood: ≤20µL l Parameters & Histograms 21 parameters and 3 histograms: WBC, Lymph#, Mid#, Gran#, Lymph%, Mid%, Gran%, RBC, HGB, MCV, MCH, MCHC, RDW-CV, RDW-SD, HCT, PLT, MPV, PDW, PCT, P-LCR, P-LCC, WBC Histogram, RBC Histogram, PLT Histogram l Reference Value Settings Preset five sets of reference values: Man, Woman, Child, Baby and General l Alarm System Multiple alarms of running status including blank counting abnormal, reagents empty, waste full, counting hole clogged, counting area leak or bubble, recorder abnormal, external printer abnormal and circuit abnormal, etc l Measures of Unclogging Treatment Back flushing, soaking and burning. Automatic unclogging treatment before and after the sample analysis l Printout English print report, optional report formats l Storage Can store more than 10,000 sample results, including parameters, histograms and patient information. Support multiple conditions combination query l Communication Open communication protocol. Support connection to LIS l Data Import & Export Import or export data via USB port l Quality Control System Include 9 QC files, automatically draw quality control chart, provide the average, SD, CV l Calibration System Support manual and automatic calibration l Software Upgrading Upgrading software via USB port l Display & Touch Screen 10.4 inch true color TFT LCD and touch screen l Printer Built-in patented structure thermal printer, paper 80mm wide, easy to load paper. Report printing takes only 5 seconds l Data Ports One network port, one RS-232 port, four USB ports l Optional External Devices with USB Port Standard 101 keyboard, mouse, barcode scanner and multiple printers l Power 220V, 50Hz Input power: ≤150VA l Operating Environment ü Environment Temperature: 10 ℃~30℃ ü Relative Humidity: ≤70% ü Atmospheric Pressure: 70.0kPa ~106.0kPa l Dimensions 368mm x 448mm x 475mm l Weight ≤23Kg | ||
Packing & Delivery
1pc/plastic bag, 1pcs/ctn
Company Profile
Shenzhen Minder Biomedical Co.,Ltd.(Mindertech) is a professional manaufactuer of medical sensors& cable assemblies for ICU and anesthesia surgery such as Spo2 sensor, ECG/EKG cable, Temperature probe, NIBP cuff, IBP cable, adapter cable, ECG electrode, EEG Cable, Bis sensor, B ultrasound probe, medical trolley etc., located in Shenzhen, China.
With a global footprint, experienced teams of design, engineering experts and extensive manufacturing capabilities, Mindertech could design, produce, test, and deliver solutions with unparalled responsiveness and speed-to-market.
Mindertech is establed by an excellent R&D team once developing OEM items for big brands., in which case Mindertech is familiar in standard R&D procedure and can provide documents such as process flow diagrams, SOP, process FMEA, control plan, measurement/test method validation, environmental compliance REACH, environmental compliance ROHS, part specific checking Aids, first artical inspection report, material/Perf test results, initial process studies(Ppk/Cpk), IQ/OQ/PQ reports etc.
Any business opportunity will be appreciated no matter it's big or small valume while OEM/ODM is welcome.
Looking forward to working for you in the near future.
With a global footprint, experienced teams of design, engineering experts and extensive manufacturing capabilities, Mindertech could design, produce, test, and deliver solutions with unparalled responsiveness and speed-to-market.
Mindertech is establed by an excellent R&D team once developing OEM items for big brands., in which case Mindertech is familiar in standard R&D procedure and can provide documents such as process flow diagrams, SOP, process FMEA, control plan, measurement/test method validation, environmental compliance REACH, environmental compliance ROHS, part specific checking Aids, first artical inspection report, material/Perf test results, initial process studies(Ppk/Cpk), IQ/OQ/PQ reports etc.
Any business opportunity will be appreciated no matter it's big or small valume while OEM/ODM is welcome.
Looking forward to working for you in the near future.
FAQ
Q:Are you a trading company or manufacturer?
A:We are a professional manufacturer with experienced R&D team once developing
cusomized products for BD, Philips, GE, Medtronic, Mindray, Stryker, Bard, Biolight, Choicemmed, Flex, ODU, Braun, Conmed etc. ODM&OEM are both welcomed.
cusomized products for BD, Philips, GE, Medtronic, Mindray, Stryker, Bard, Biolight, Choicemmed, Flex, ODU, Braun, Conmed etc. ODM&OEM are both welcomed.
Q:Could you pass on-site auditing or supplier review?
A: Sure, we have perfect management procedure,
quality manual and rich auditing experience.
quality manual and rich auditing experience.
Q:Could you pass supplier verification and qualification?
A:Yes, we are experienced in following PPAP (Production Part Approval Process) Workbook and offering process flow diagrams, process FMEA, control plan,measurement/test method validation, environmental compliance REACH, environmental compliance ROHS, part specific checking aids,FAI, material/perf test results, initial process studies(Ppk/Cpk), IQ/OQ/PQ protocols&reports, transport packaging, validation records and warrant etc.
Q:How do you guarentee your quality?
A: Mindertech company has strict management procedure about IQC(Raw materials are sourced from Phlips/BD/GE/Mindray approved suppliers, quality guaranteed), FAI(first article inspection for all
production and trial production would be executed before mass production and after parts verfication&qualification), IPQC, 100%FQC and OQC. OQC Report and CoC will be shipped along with the products you ordered. Besides, in-house R&D and testing devices, materials with RoHs Complies, and all patient contact materials are latex free and tested with Biocompatibility report from third party.
production and trial production would be executed before mass production and after parts verfication&qualification), IPQC, 100%FQC and OQC. OQC Report and CoC will be shipped along with the products you ordered. Besides, in-house R&D and testing devices, materials with RoHs Complies, and all patient contact materials are latex free and tested with Biocompatibility report from third party.
Q:Do you provide samples? Is it free or charged?
A: Mindertech company has sampling team and samples will be offered for some
sampling fee which will be refunded in next bulk order.
sampling fee which will be refunded in next bulk order.
Q:Do you have MOQ?
A: Depends on what you need. Please send inquiry or email for more details.
Q:Where is your facility?
A: Mindertech company locates at Shenzhen, China, 30mins away from Shenzhen Airport.
Q:What's the lead time since we place an order to you?
A: Negotiable, generally 1-3 working days for small order, 1-2 weeks for bulk order.
