30 33 40 41 amp 30a 50a 60amp 66a 600w 800w 1000w 1200w 220v 36v 48v 60v Dc Switching Power Supply
- Category: >>>
- Supplier: Huizhou City Kechuangli Electronics Co. Ltd.
Share on (1600442920196):
Product Overview
Description
Recommend Products
Product Description
30 33 40 41 amp 30a 50a 60amp 66a 600w 800w 1000w 1200w 220v 36v 48v 60v Dc Switching Power Supply
Features
* Universal AC input / Full range
* Protections: Short circuit / Overload / Over voltage / Over temperature
* Cooling by free air convection
* LED indicator for power on
* 100% full load burn-in test
* No load powewr consumption <0.5W
* All using 105°C long life electrolytic capacitors
* Withstand 300VAC surge input for 5 seconds
* High operating temperature up to 70°C
* Withstand 5G vibration test
* High efficiency, long life and high reliability
* 2 years warranty
800W POWER SUPPLY SPECIFICATION | ||||||
Output Power | 800w | Output voltage tolerance | ±0.1% | |||
Output Type | Single | Temperature coefficient | ±0.03%℃(0-5℃) | |||
INPUT VOLTAGE | 110-264VAC | OVER VOLTAGE PROTECTION | YES | |||
OUTPUT VOLTAGE | 12V±0.5% | OVER TEMP. PROTECTION | YES | |||
EFFCIENCY | ≥80% | OVER LOAD PROTECTION | YES | |||
Start Time | 200ms | Impulse current | CCA 30A/110V 10A/264V | |||
Rise Time | 50ms | Output current range | 9.5A/110V 6.1A/264V | |||
Hold Time | 20ms | Leakage current | 〈0.5mA/260VAC | |||
Ripples & noise | 500mVp-p | Operating temperature, humidity | -10℃~+60℃，20%~90%RH | |||
Incoming line stability | ±0.5% | Storage temperature, humidity | -20℃~+85℃，10%~95%RH | |||
Load stability | ±0.5% | Resistance to pressure | Input-output；Input -enclosure；Output-enclosure：1.5KVAC | |||
BST Factory
Product packing & delivery
We accept OEM/ODM orders.
we have professional artists, can provide you with customized services for free!
25pcs/CTN;31KG/CTN;Carton size :52*25.5*46CM
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. Who are we?
We are specialized in the research and development and production of switching power supply manufacturers. Our factory is located in Shenzhen, China. We have a professional R & D team and production team.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
All of our products have passed 100% loading aging test;
3.What after-sale service can you provide?
All of our products come with a two-year warranty and if the product you receive has any quality problems within two years of receiving the package,We will send you a new one free of charge on the next order.
4. Why should you buy from us not from other suppliers?
We are specializing in researching & development, producing and selling switching power supply for more than 15 years. We provide perfect solutions on Power Supply , with excellent quality product, competitive price and fast delivery services.
5. What services can we provide?
Accepted Delivery Terms: EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Japanese,Russian,Korean
6.Can I customize products?
Yes,We accept OEM/ODM orders, we have professional artists, can provide you with customized services for free.
We are specialized in the research and development and production of switching power supply manufacturers. Our factory is located in Shenzhen, China. We have a professional R & D team and production team.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
All of our products have passed 100% loading aging test;
3.What after-sale service can you provide?
All of our products come with a two-year warranty and if the product you receive has any quality problems within two years of receiving the package,We will send you a new one free of charge on the next order.
4. Why should you buy from us not from other suppliers?
We are specializing in researching & development, producing and selling switching power supply for more than 15 years. We provide perfect solutions on Power Supply , with excellent quality product, competitive price and fast delivery services.
5. What services can we provide?
Accepted Delivery Terms: EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union;
Language Spoken:English,Chinese,Japanese,Russian,Korean
6.Can I customize products?
Yes,We accept OEM/ODM orders, we have professional artists, can provide you with customized services for free.
