Outdoor indoor glass vacuum lifter With flip and rotation function with CE certificate
- Category: Glass Processing Machinery >>>
- Supplier: Shandong,Care,Machinery,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Video display
Equipment Features:
1,The lifter is widely used for lifting, handling and moving of glass, steel and wood sheet and marble.
2,Adjustable manual vacuum lifter is a glass handling equipment with flexible structure and simple operation.
3,It is able to assemble in various ways in accordance with demand.
4,By changing position of suckers can realize absorbing glass with different shapes and dimensions.
5,All functions can be done by hand, dispensed with electricity, safe and reliable.
6,It is one of the most comonly used equipments for curtain wall installation and glass deep processing enterprises.
3,It is able to assemble in various ways in accordance with demand.
4,By changing position of suckers can realize absorbing glass with different shapes and dimensions.
5,All functions can be done by hand, dispensed with electricity, safe and reliable.
6,It is one of the most comonly used equipments for curtain wall installation and glass deep processing enterprises.
Recommend Products
Why Choose Us
Products Description
A variety ofstructure suction cups available for configurations.
DC 12V battery powered, no cable connection required
Vertical 90° turning and horizontal 360° rotating.
Digital vacuum pressure display and LCD battery colume display.
Low pressure alarm with acoustic and light.
Sealed cover for components protection, suited for outdoor use.
Product Paramenters
Parameters of Care glass vacuum lifter | ||||||
Model | SD400-03 | SD600-03 | SD800-03 | |||
Rated load | 400kg | 600kg | 800kg | |||
Sucker diameter | 250mm | 250mm | 250mm | |||
Sucker qty | 4 | 6 | 8 | |||
Vertical rotation | 0°-90° | 0°-90° | 0°-90° | |||
Horizontal rotation | 360° | 360° | 360° | |||
Charger | AC 220V | AC 220V | AC 220V | |||
Power | 12V battery | 12V battery | 12V battery | |||
Weight | 80kg | 100kg | 120kg | |||
Note: various lifting capacity and power supply available. | ||||||
