Electric Aerial Order Picker Electric Stacker
- Category: >>>
- Supplier: Qingdao Olift Equipment Co. Ltd.
Share on (1600449128702):
Product Overview
Description
Whole-electromotion aerial order picker
Main specifications
Working height: 2.70m, 3.30m, 4.0m and 4.50m
Safety load: 300kg important features
Large cargo platform, wide applicability
Tilt protection system, high safety
Standard transportation forklift holes, convenient for transportation
0 degree turning radius, flexible operation
Model Number | FH-2.7-YZ | FH-3.0-YZ | FH-4.5-YZ | H-4.5-YZ | |
Max. Platform Height(H) | mm | 2700 | 3000 | 4000 | 4500 |
Max. Machine Height(H1) | mm | 4000 | 4450 | 5000 | 6000 |
Ground Clearance(H2) | mm | 45 | 45 | 45 | 45 |
Lift Rated Capacity | kg | 300 | 300 | 300 | 300 |
Platform Size | mm | 600x700 | 600x700 | 600x700 | 600x700 |
Min.turning Radius | mm | 1600 | 1600 | 1690 | 1690 |
Max. Climbing Capacity | % | 15~20 | 15~20 | 15~20 | 15~20 |
Driving Wheel Size | mm | Φ230x80 | Φ230x80 | Φ230x80 | Φ230x80 |
Caster Size | mm | Φ230x80 | Φ230x80 | Φ230x80 | Φ230x80 |
Driving Motor | v/kw | 2x24/0.4 | 2x24/0.4 | 2x24/0.4 | 2x24/0.4 |
Lifting Motor | v/kw | 24/1.6 | 24/1.6 | 24/1.6 | 24/1.6 |
Aneroid Battery | v/Ah | 2x12/100 | 2x12/100 | 2x12/100 | 2x12/100 |
Charger | v/A | 24/15 | 24/15 | 24/15 | 24/15 |
Overall Length(A) | mm | 1540 | 1540 | 1620 | 1620 |
Overall Width(B) | mm | 760 | 760 | 760 | 760 |
Overall Height(C) | mm | 1900 | 2050 | 1920 | 2080 |
Overall Net Weight | kg | 600 | 620 | 830 | 850 |
