JLS будущее Optiplex 7090MT i9-10900K/8G/1T 500W башня настольный компьютер
- Category: Desktops >>>
- Supplier: Beijing,Xinqidian,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Specification
Feature | OptiPlex 7090 Tower Technical Specifications |
Processor | 10th Generation Core™ i5-10400, 12MB Cache, 6 Core, 12 Treads, 2.9GHz to 4.3GHz, 65W 10th Generation Core™ i5-10500, 12MB Cache, 6 Core, 12 Treads, 3.1GHz to 4.5GHz, 65W 10th Generation Core™ i5-10600, 12MB Cache, 6 Core, 12 Treads, 3.3GHz to 4.8GHz, 65W 10th Generation Core™ i7-10700, 16MB Cache, 8 Core, 16 Treads, 2.9GHz to 4.8GHz, 65W 10th Generation Core™ i9-10900, 20MB Cache, 10 Core, 20 Treads, 2.8GHz to 5.2GHz, 65W 10th Generation Core™ i3-10105, 6 MB Cache, 4 Core, 8 Threads, 3.7 GHz to 4.4 GHz, 65 W 10th Generation Core™ i3-10305, 8 MB Cache, 4 Core, 8 Threads, 3.8 GHz to 4.5 GHz, 65 W 10th Generation Core™ i5-10505, 12 MB Cache, 6 Core, 12 Threads, 3.2 GHz to 4.6 GHz, 65 W 11th Generation Core™ i5-11400, 12 MB Cache, 6 Core, 12 Threads, 2.6 GHz to 4.4 GHz, 65 W 11th Generation Core™ i5-11500, 12 MB Cache, 6 Core, 12 Threads, 2.7 GHz to 4.6 GHz, 65 W 11th Generation Core™ i5-11600, 12 MB Cache, 6 Core, 12 Threads, 2.8 GHz to 4.8 GHz, 65 W 11th Generation Core™ i7-11700, 16 MB Cache, 8 Core, 16 Threads, 2.5 GHz to 4.9 GHz, 65 W 11th Generation Core™ i9-11900, 16 MB Cache, 8 Core, 16 Threads, 2.5 GHz to 5.2 GHz, 65 W 11th Generation Core™ i7-11700K, 16 MB Cache, 8 Core, 16 Threads, 3.6 GHz to 5.0 GHz, 125 W 11th Generation Core™ i9-11900K, 16 MB Cache, 8 Core, 16 Threads, 3.5 GHz to 5.3 GHz, 125 W |
Chipset | Q570 Chipset |
Operating System Options | Windows 10 Home, 64-bit Windows 10 Pro, 64-bit Windows 10 Pro Education, 64-bt Ubuntu® Linux® 20.04 LTS, 64-bit |
Video Card | UHD 630 Graphics for 10th Generation Core™ i3/i5 processors UHD 730 Graphics for 11th Generation Core™ i5-11400 processors UHD 750 Graphics for 11th Generation Core™ i5/i7/i9 processors GeForce® RTX 3070, 8 GB, GDDR6 (optional) GeForce® GTX 1660 Super™, 6 GB, GDDR6 (optional) Radeon™ RX640, 4 GB, GDDR5 (optional) Radeon™ 550, 2GB, GDDR5 (optional) Radeon™ 540, 1GB, GDDR5 (optional) |
Memory | 4 GB, 1 x 4 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 8 GB, 1 x 8 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 8 GB, 2 x 4 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 16 GB, 1 x 16 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 16 GB, 2 x 8 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 16 GB, 4 x 4 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 32 GB, 1 x 32 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 32 GB, 2 x 16 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 32 GB, 4 x 8 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 64 GB, 2 x 32 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 64 GB, 4 x 16 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9, 3200 MHz for 11th Generation Core i5/i7/i9 processors 128 GB, 4 x 32 GB, DDR4, 2666 MHz for 10th Generation Core i5, 2933 MHz for 10th Generation Core i7/i9 and 11th Generation Core i5/i7/i9 processors Note: Memory speed varies by different type of DPC (DIMM per Channel) installation. |
Ports | Front: 1 USB 2.0 port with PowerShare 1 USB 3.2 Gen 2 Type-A port 1 USB 3.2 Gen 2x2 Type-C port 1 USB 2.0 port 1 Universal Audio Jack Rear: 1 USB 3.2 Gen 2 Type-A port 2 USB 2.0 ports with Smart Power On 3 USB 3.2 Gen 1 Type-A ports 1 USB 3.2 Gen 2 Type-C® Alt-Mode (optional) |
Optical Drive | 8x DVD-ROM 8x DVD+/-RW |
Slots | 1 SD-card slot (optional) 1 full-height Gen 4 PCIe x16 slot 1 full-height PCIe x16 (wired x4) slot 1 full-height PCI-32 slot 1 full-height PCIe x1 slot 1 M.2 2230 slot for Wi-Fi 1 M.2 2230/2280 slot for SSD 1 M.2 2280 slot for SSD 4 SATA slots for 2.5-inch HDD/SSD, and slim Optical Drive |
Primary Hard Drive | 2.5-inch, 1 TB, 5400 RPM, SATA, HDD 2.5-inch, 2 TB, 5400 RPM, SATA, HDD 2.5-inch, 500 GB, 7200 RPM, SATA, HDD 2.5-inch, 1 TB, 7200 RPM, SATA, HDD 2.5-inch, 500 GB, 7200 RPM, SATA, HDD, Self-Encrypting, Opal 2.0, FIPS 3.5-inch, 500 GB, 7200 RPM, SATA, HDD 3.5-inch, 1 TB, 7200 RPM, SATA, HDD 3.5-inch, 2 TB, 7200 RPM, SATA, HDD 3.5-inch, 4 TB, 5400 RPM, SATA, HDD M.2 2230, 128 GB, PCIe NVMe Gen3 x4, Class 35 SSD M.2 2230, 256 GB, PCIe NVMe Gen3 x4, Class 35 SSD M.2 2230, 512 GB, PCIe NVMe Gen3 x4, Class 35 SSD M.2 2280, 256 GB, PCIe NVMe Gen3 x4, Class 40 SSD M.2 2280, 512 GB, PCIe NVMe Gen3 x4, Class 40 SSD M.2 2280, 1 TB, PCIe NVMe Gen3 x4, Class 40 SSD M.2 2280, 2 TB, PCIe NVMe Gen4 x4, Class 40 SSD M.2 2280, 256 GB, PCIe NVMe Gen3 x4, Class 40 SSD, self-encrypting drive M.2 2280, 512 GB, PCIe NVMe Gen3 x4, Class 40 SSD, self-encrypting drive M.2 2280, 1 TB, PCIe NVMe Gen3 x4, Class 40 SSD, self-encrypting drive |
Dimensions | Front Height: 14.45 in. (367.00 mm) Rear Height: 14.45 in. (367.00 mm) Width: 6.65 in. (169.00 mm) Depth: 11.84 in. (300.80 mm) Weight (min): 14.46 lb (6.56 kg) Weight (max): 22.53 lb (10.22 kg) |
Power | 260 W typical 85% Efficient PSU, 80 Plus Bronze 300 W typical 92% Efficient PSU, 80 Plus Platinum 360 W typical 92% Efficient PSU, 80 Plus Platinum 500 W typical 92% Efficient PSU, 80 Plus Platinum |
Detail Images
Front View details:
1. Hard-disk drive cover
2. Optical Disk Drive (optional)
3. Power button with diagnostic LED
4. SD 4.0 card reader (optional)
5. Hard-disk drive activity light
6. Universal audio jack port
7. USB 2.0 port with PowerShare
8. USB 2.0 port
9. USB 3.2 Gen2x2 capable Type-C port with PowerDelivery
10. USB 3.2 Gen 2 port
2. Optical Disk Drive (optional)
3. Power button with diagnostic LED
4. SD 4.0 card reader (optional)
5. Hard-disk drive activity light
6. Universal audio jack port
7. USB 2.0 port with PowerShare
8. USB 2.0 port
9. USB 3.2 Gen2x2 capable Type-C port with PowerDelivery
10. USB 3.2 Gen 2 port
Back View details:
1. Line-out re-tasking Line-in audio port
2. Two DisplayPort 1.4 ports
3. Serial port
4. PS/2 port for keyboard
5. One USB 3.2 Gen 2 port
6. Three USB 3.2 Gen 1 ports
7. Two USB 2.0 ports with Smart Power On
8. Expansion card slots
9. Power connector port
10. Power supply diagnostic light
11. Knock out slot (optional SMA connector)
12. Kensington security-cable slot
13. RJ-45 port 10/100/1000 Mbps
14. PS/2 port for mouse
15. Padlock loop
16. VGA/DisplayPort 1.4/H~ 2.0b/USB 3.2 Gen2 Type-C Port with Alt-mode (optional)
17. Release latch
2. Two DisplayPort 1.4 ports
3. Serial port
4. PS/2 port for keyboard
5. One USB 3.2 Gen 2 port
6. Three USB 3.2 Gen 1 ports
7. Two USB 2.0 ports with Smart Power On
8. Expansion card slots
9. Power connector port
10. Power supply diagnostic light
11. Knock out slot (optional SMA connector)
12. Kensington security-cable slot
13. RJ-45 port 10/100/1000 Mbps
14. PS/2 port for mouse
15. Padlock loop
16. VGA/DisplayPort 1.4/H~ 2.0b/USB 3.2 Gen2 Type-C Port with Alt-mode (optional)
17. Release latch
