REAN RRAC3O G 000 pole AC power outlet connector with D Size mounting flange
- Category: >>>
- Supplier: Shenzhen Pawpaw Electronic Technology Co. Ltd.
Share on (1600451684153):
Product Overview
Description
Products Description
REAN RRAC3O-G-000 pole AC power outlet connector with D-Size mounting flange
Article Name | RRAC3O-G-000-0 |
Connection Type | Power Connectors |
Details | 3/16" flat tap contacts, blue housing, power inlet |
Connection Type | Power Connectors |
Rated current per contact | 16 A / 20 A RMS |
Rated Voltage | 250 V / 127 V AC |
Cable connector contacts | Brass, Ag plated |
Receptacle contacts | Bronze, Ag plated |
Chucks | POM |
Flammability | UL94 V-0 |
Temperature range | -30 °C to +80 °C |
Protection class (mated) | IP 20 |
Safety Requirments | EN / IEC61984 |
Solderability | complies with IEC68-2-20 |
Appllications | ||
HiFi playback equipment / HIFI decoder | Mixer | |
Audio tester | Audio | |
Professional audio equipment | Power amplifier | |
High-end microphone equipment | Sound card | |
power connectors--power chassis
FEATURES
1. 16A / 250V , 20A / 127V
2. Twist locking latching system
3. UL94 V-0 rate materials
4. VDE certification
5. UL60320-1 certification
APPLICATIONS
1. Mixer
2. HiFi playback devices
3. Audio precison
4. Professional audio equipment
5. High-end microphone equipment
Related Products
PXVF3500-KIT XMOS Linear usb 4 microphone array
[XMOS] P3510-2MIC Board USB 2 MIC linear microphone array, 5m far-field voice capture, suitable for conference calls & ASR
[XMOS] PXVF3000-KIT Board USB 4-channel circular microphone array, 5m far-field voice capture, suitable for conference calls
Local voice control , offline ASR , key word detected
USB 16 Channels Digital Microphone Capture, low latency and real-time ,original signal of 16 microphones voice capture
[XMOS] PXVF3500-KIT Board USB 4-channel linear microphone array, 5m far-field voice capture, suitable for conference calls
Company Profile
Shenzhen Pawpaw Electronic Technology Co., Ltd is a is a tech company, which focuses on R&D of audio and audio PCBA solutions. We own a group of loved technology engineer team, which haveexperience in development of embedded real-time operating systems. We focus on R&D of audio digitalinterface converter technology and provide total solution, so we can quickly provide technical services toour customers and help their products to make market as soon as possible.
Our technical solution have a full rang of audio digital interface converter, such as USB audio andmicrophone array. In recent years, our R&D is on USB audio solution, we provide multiOchannel andmulti-audio interface customized solution to audio manufacturers. Since the end of 2015 we start our R&D on microphone array. We provide microphone array PCBA solutions, focuses on digital meetingdevice and AIOT device. We provide high quality technical services so that can help our customer andpartner quickly to make market. We believe that we can become an important microphone array solutionprovider in the development of Al market.
Why Choose Us
PAWPAW One-Stop Solution Service
IC Supply：PAWPAW Electronics' business model is based on chip supply and sales, representing several audio chip product lines, including XMOS, NEUTRIK, Everest-semi, InvenSense , Rean etc.
Technical support： In addition to chip supply we also provide mature solutions and technical support.
Technical support： In addition to chip supply we also provide mature solutions and technical support.
Application Solutions： PAWPAW combines XMOS and ESS product lines to provide a complete solution for USB Audio in the audio HiFi field, providing 2-way/4-way microphone array solutions, single microphone/microphone array wake-up word and command word solutions.
