Construction Machinery Stone Crusher Production Line hydraulic rock Impact Hammer Crusher
- Category: >>>
- Supplier: Shanghai,ZENITH,Mineral,Co.,Ltd.
Share on:
Product Overview
Description
Construction Machinery Stone Crusher Production Line Impact Hammer Crusher
Product Description
 | Construction Machinery Stone Crusher Production Line Impact Hammer Crusher
impact hammer crusher (Also known as “European Impact Crusher”) is mainly used in metallurgy, mine, cement, chemical engineering, fire resistant materials, ceramics and other industries, as well as in the expressway construction, water conservancy projects, aggregate and machine-made sand fields, etc.
Product Features: The use of automated hydraulic jacking device makes checks and maintenance easier and reduces labor costs. |
Construction Machinery Stone Crusher Production Line Impact Hammer Crusher introduction:
Top Technology, Unique Design
| Cast Steel Structure, High Holding Capacity
|
Semi-Automatic Operation Makes Maintenance Easy And Convenient
| Simplified Technological Process, Wide Applications
|
Digitalized Processing, Higher Precision
| Sufficient Supply Of Spare Parts, Worry-Free Operation
|
Construction Machinery Stone Crusher Production Line Impact Hammer Crusher working principle:
impact hammer crusher breaks materials with impact force. When materials enter the working area of hammer, they may be crushed under the high-speed shock and then thrown onto the impact device above the rotor for another crushing. Next, materials bounce from the lining plate to the working area of hammer again. This process repeats continuously until materials reach qualified granularity and are discharged. Adjusting the gap between the impact rack and the rotor rack can change the granularity and shape of finished products. Behind the impact plate is a spring safety device. When unbreakable materials enter the crushing chamber, the impact rack goes backwards to discharge unbreakable materials out of the crusher.
Construction Machinery Stone Crusher Production Line Impact Hammer Crusher album:
Construction Machinery Stone Crusher Production Line Impact Hammer Crusher parameters:
| Model | Rotor spec (mm) | Feed opening (mm) | Maximum feeding size (mm) | Capacity(t/h) | Power(kw) | Overall dimension (mm) |
| PFW1214II | 1150×1400 | 1100×1430 | 500 | 130-200 | 132 | 2400×2310×2550 |
| PFW1315II | 1300×1500 | 1200×1530 | 600 | 180-320 | 200 | 2700×2570×2800 |
| PFW1318II | 1300×1800 | 1200×1830 | 700 | 240-400 | 250 | 2700×2870×2800 |
| PFW1415II | 1400×1500 | 1450×1530 | 700 | 300-480 | 250 | 2900×2700×3000 |
| PFW1214Ⅲ | 1150×1400 | 570×1430 | 250 | 90-170 | 132 | 2550×2310×2100 |
| PFW1315Ⅲ | 1300×1500 | 625×1530 | 300 | 180-270 | 200 | 2960×2570×2380 |
| PFW1318Ⅲ | 1300×1800 | 625×1830 | 300 | 220-300 | 250 | 2960×2870×2380 |
| PFW1415Ⅲ | 1400×1500 | 800×1530 | 350 | 280-350 | 250 | 3120×2650×2660 |
Note:
1.The bulk specific weight is calculated by 1.6t/m³. When the width of the feeding port is above 600mm, it is a large-scale machine while when the width ranges from 300 to 600mm, it is a medium-sized machine.
2.Product pictures and parameters about models, data, performances and specifications on this website are for reference only. There is a chance that ZENITH may make changes on above-mentioned information. For specific messages, please refer to the real objects and user manuals. Without special instructions, ZENITH keeps the right to explain all data involved in this website.
Company Information
A VARIETY OF TRUSTED EXPERIENCE ZENITH has a variety of professional, reliable and efficient crushing lines all around the world. So customers have great confidence in us. |
INFINITE BRAND VALUE What ZENITH is doing is customizing economical and suitable production lines for customers and building brand value. |
1200,000 SQUARE METERS OF PRODUCITION AREA 6 large-scale manufacturing bases occupy 1200,000 square meters in total. So quick delivery is a matter of course. |
Shanghai Zenith Mineral Co., Ltd. is a hi-tech, engineering group. We are specialized in the research, development, and production of industrial crushing, powder grinding, mineral processing equipments and other related devices. Our products have been sold to 120 countries and areas of Southeast Asia, East Europe, South America, the Middle East and Africa etc, and more foreign markets will be promoted in future.
Zenith Factory
Headquarter of Zenith is located in Shanghai, China and now we have two manufacturing bases as our strong support. One is located in Shanghai about 450,000 square meters, and the other is in Qidong city, about 600,000 square meters. It takes about one-hour driving from Shanghai to Qidong city.
Exhibition
Zenith participate in various exhibitions frequently,such as Bauma China,China Import and Export Fair , Asia-pacific's International Mining Exhibition, Bauma Africa, CONEXPO Latin America , etc.
Our Services
Pre-sales Service: The wide product range enables us to provide our customers with stand-alone machines or complete processing plants. Based on our customers’ request and budget, our experts make efficient, reliable solutions. Following customers’ order we produce strictly, what’s more, before placing the order every customer has the chance to visit zenith working machines or complete plant in the site. To ease the trip for every visitor to China, in particular the first-time visitor, we provide FOR FREE all relevant visitor-friendly services including invitation letter preparation, hotel reservation, airport pick-up, incity transportation, and sightseeing guide, etc.
|
After-sales Service: Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customers’ plants. Necessary training about machine daily maintenance to local workers is provided also. |
Packaging & Shipping
Ways of Packing:
1.Sand blasting, coat with high quality paint;
2.Product wrap by PP-Bubble
3.Load container, Spear Parts in wooden case.
Transportation:
1. By sea Freight;
2. MSK/MSC/APL/EMC/WANHAI/KLINE
3. We will remind you before boat arrival
Get Price
If you are interested with our products, please don't hesitate to contact us now!
You can tell me the following questions, Then I can send you accurate quotation, including additional discount!
1. Which machine do you need? like stone crusher, grinding mill or beneficiation machine, etc.
2. what is your raw material plan to process? like limestone, granite or inron ore, etc.
3. The capacity you need. Like 100 tones per hour or 2000 tones per day.
4. Your contact information. Both Email and phone number are essential, we can contact you easier.
Now,please click the following contact to send us email or chat online!
