Product Overview
Description
Multifunctional Temperature And Humidity Test Chamber Best Price frequency conversion Save Energy
Product Description
Programmable constant temperature and humidity testing machines applied to test the materials in
heat-resistance, cold-resistance, dry-resistance, moisture-resistance . The language can choose either
English or Chinese and with thetouch-screen liquid crystal display screen, simple cooperate and program easy to edit. It can show the system operating data, implementation and set-up process curve. Trouble occurs in operation, the screen automatically displays the trouble and provide a method for troubleshooting.
Technical Parameters:
Model | ZME -80 (A~G) | ZME -150 (A~G) | ZME -225 (A~G) | ZME -408 (A~G) | ZME -608 (A~G) | ZME -800 (A~G) | ZME -1000 (A~G) |
Inside size WxHxD (cm) | 40x50x40 | 50x60x50 | 50x75x60 | 60x85x80 | 80x95x80 | 100x100x80 | 100x100x100 |
Outside size W*H*D (cm) | 90x136x94 | 100x146x104 | 100x161x117 | 110x171x137 | 130x181x137 | 150x186x137 | 150x186x157 |
Temperature range | -70 deg~+100(150)deg | ||||||
Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific condition) | ||||||
Accuracy/ uniformly | ±0.1deg ±0.1%R.H./±1.0deg ±3.0%R.H. | ||||||
Accuracy/ volatility | ±1.0deg ±2.0%R.H./±0.5deg ±2.0%R.H. | ||||||
Heating/ cooling time | 4.0/min(heat),1.0/min(cool) (specific condition:5~10deg/mm) | ||||||
Inside material | Stainless steel SUS 304# | ||||||
Insulation material | High-temperature high-density amino acid ethyl ester foam insulation materials | ||||||
Cooling system | Air-cooled/single-stage compressor(-20deg), wind,water cooled/two-stage compressor(-40~-70deg) | ||||||
Protection | compressor overload switch,high and low pressure protection switch, over-humidity-temperature protection switches,fuses,warning system | ||||||
Accessories | recorder(purchase),view window,50mm testing hole,PL lamp,clapboard, Dry and wet gauze ball | ||||||
Controller | South Korea TEMI300 digital controller | ||||||
Compressor | France Taikang | ||||||
Power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz | ||||||
Features:
1.High-texture appearance, the surface handled through the matte stripes, and use of planar non-reactive handles, easy to operate, safe and reliable.
Applicable industries
2.Rectangular complex glass window can be viewed the testing sample, windows with anti-sweat heater
device thatprevents water vapor condensation, and high-brightness PL light.
3.Double-insulated airtight container, which can effectively isolate the internal temperature of leakage.
4.With an external water supply system can be easy to supply water and automatically reuse.
5.Compressor circulatory system from French "Taikang", more effective removal of oil between the condenser and thecapillary and use environmentally refrigerants (R23, R404, R507).
6.Controller imported LCD display screen can be displayed measuring values and setting the value and time.
7.Controller with multi-segment program edited, temperature and humidity can be controlled quickly (OUICK) or slope(SLOP).
8.Built-in mobile pulley easy to move and has a strong positioning screw fixed position
Corresponding standard:
1. GB11158 Technical conditions for high-temperature testing box
2. GB10589-89 Technical conditions for low-temperature testing bOX
Applied to control the product quality, such as electronic, plastic products, electrical appliances, instruments, food,vehicles, metals, chemicals, building materials, aerospace, medical care ... and so on.
Detailed Configuration and function of software :
wind circulative system
1.Using multi-wing centrifugal Rewind fans, strengthen the axis is made of aluminum alloy in
order to attain loop forced convection
2,Stainless steel added long axis
3,Stainless Steel Multi-blade centrifugal wind wheel
water Supply system
4,with water tank at the back
5,automatically supply water
3,warning for the shorage of water
cooling system(diego-style,single machine,refrigerator;)
6,compressor:France“Taikang”Hermetic Refrigeration Compressor TFHK2522K two unit
7,refrigerator:Air-cool condenser coil
Product Detailes
Related Products
HOME
Company Profile
Dongguan ZME Machine Trading Co.,td is one of the leading manufacturers of advanced testing instruments, founded on 2000, located in Dongguan, Guangdong province in China. Dongguan ZME Machine Trading Co.,td located in Dongguan city, covers an area of 6000 square meters, take the lead in introducing the CNC processing center and NC lathe and other advanced equipment in 2010. Carried on several listed company lab, quality institutions, Tsinghua University, Aeronautics University's project. We have 30000+ buyers in domestic market, succeed in establishing the branch companies and maintenance department in Dongguan, Shanghai, Beijing, Jinjiang, Wuhan, Chongqing, Shenyang, Changsha. Our products owned CE/ISO/ASTM/ ROSH/UL certification, and have exported to more than 70 countries like the USA, Germany, South Korea, Greece, India, Singapore, Brazil, Iraq, Saudi Arabia and so on.
ZME Instrument owned CE/ISO/ASTM/ROSH/UL certification, and have exported to more than 70 countries like the USA, Germany, South Korea, Greece, India, Singapore, Brazil, Iraq, Saudi Arabia and so on. Lixian Instrument have a professional R & D team and a reliable quality management system, which introduced the CNC processing center and CNC lathe and other advanced equipment in 2010, successfully obtained the CMC measurement certificate and passed ISO 9001 system authentication.
Package & transport
FAQ
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services. Free Non-consumable components will be provided if any performance failure occurs within 12 months caused by non-human damage.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory* trade (integration).15 years focusing on test instruments field. 6 years exporting experience, warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 25 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support, and help customer solve problems encountered while using our product, handles guest problems and complaints professionally and timely. All instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. Engineers would be gone abroad to training, repair and others help you need.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
