Product Description
PE Embossed & Lamination Film Machine is designed for producing embossed film, top-grade laminating on nonwoven, and laminating on paper with LLDPE, LDPE, HDPE and EVA.
Features of PE Embossed & Lamination Film Machine
1.Co-extruded by two or more extruders to produce multi-layer lamination film by means of one-step processing. Less production process, low energy consumption, and low cost.
2.Equipped with touch screen and PLC.
3.Newest designed winding tension control unit to ensure precise, stable, reliable tension control.
Characteristics of Product
1.The multi-layer co-extruded film from cast process has superior properties from different raw materials and good appearance because it combines different raw materials with different properties during extrusion and gets complementation in properties, such as anti-oxygen and dampproof barrier property, permeability resistance, transparency, fragrance keeping, heat preservation, anti-ultraviolet radiation, pollution resistance, low temperature heat sealing and high strength, rigidity and hardness etc. mechanical properties.
2.Thinner and better thickness uniformity.
3.Good transparency and heat sealing.
4.Good inner stress and printing effect.
Main Applications of Product
1.Medical and hygienic products: medical operation gowns, disposable sheet, sanitary towel, baby diaper, pet cushion, shoe cover, headgear etc.
2.Commodities: table cloth, glove, apron, shower curtain, western-style clothes cover, raincoat, beach umbrella, chair cover, wardrobe cover, blanket cover etc.
3.Industrial products: typewriter cover, computer cover, air conditioner cover, photocopier cover and various dustproof covers etc.
Model(mm) SJLM-TH-Z | 1600 | 2200 | 1600 | 2200 |
Screw Diameter(mm) | 125 | 135 | 80/110 | 90/110 |
L/D Ratio of Screw | 32:1 | 32:1 | 32:1 | 32:1 |
Width of Die (mm) | 1900 | 2500 | 1900 | 2500 |
Width of Finished Film(mm) | 1600 | 2200 | 1600 | 2200 |
Thickness of Finished Film (mm) | 0.02-0.20 | 0.02-0.20 | 0.02-0.20 | 0.02-0.20 |
Structure of Film | A | A | A/B, A/B/A | A/B, A/B/A |
Max. Extrusion Capacity(kg/h) | 320 | 450 | 320 | 450 |
Design Line Speed (m/min) | 120 | 120 | 120 | 120 |
Total Installed Power (kw) | 230 | 280 | 240 | 330 |
Overall Dimensions(L×W×H)(m) | 15×11×4.8 | 15×11.5×4.8 | 15×12.5×5 | 16×13×5 |
Weight(T) | 30 | 35 | 35 | 40 |
Packaging & Shipping
PE Embossed & Lamination Film Machine is packaged by wooden boxes for export. Welcome contact Vivian wechat & whatsapp 008618032755245
Our Services
pre-sales and after-sales services
