SIM7600CE Arduino expansion Board

Product Overview

Description

SIM7600CE



SIM7600CE-T 4G(LTE) Shield is an Arduino expansion Board based on 4G/3G/2G communication and GNSS positioning technology, small as a credit card and compatible with controller boards like Arduino UNO, Leonardo and Mega. It accords with standard Arduino interface.

SIM7600CE-T is a complete multi-band LTE-TDD/ LTE-FDD/HSPA+/TD-SCDMA/EVDO and GSM/GPRS/EDGE module solution which supports LTE CAT4 up to 150Mbps for downlink and 50Mbps for uplink data transfer.

With stable performance, this small cost-effective expansion shield can realize SMS and data transmission in a pretty low power consumption. Besides, it adopts the latest SIM7600CE module. Compared with other GSM/GPRS/GPS modules on the market, this module is well advanced in stable performance and powerful function such as 4G communication and accurate GNSS positioning.



• Operating Voltage: 5V


• Input Power: VIN(7-23V)/USB(5V)


• Support Network:



  • TDD-LTE B38/B39/B40/B41


  • FDD-LTE B1/B3/B8


  • TD-SCDMA B34/B39


  • WCDMA/HSDPA/HSPA+ B1/B8


  • CDMA 1X/EVDO BC0


  • GSM/GPRS/EDGE 900/1800 MHz






• 4G Communication Rate:



  • Uplink Rate: 50Mbps


  • Downlink Rate: 150Mbps






• Control via AT Commands (3GPP TS 27.007,27.005 and SIM7500_SIM7600 Series_AT Command)


• Support GNSS (Global Navigation Satellite System)


• Support Low-power Consumption Mode: 20mA@7V Flight Mode


• Support LED Status Display: display the power supply status, network connection and operating mode


• Operating Temperature: -40℃~85℃


• Dimension: 6954mm/2.712.13”
