Product Overview

Description





SMRV SERIES WORM
GEAR UNITS








High

output

torque




Products Description


Technical performance and selection reference


Motor power
Model
speed ratio
output speed
output toruqe

0.25kw 1400rpm
RV075
60
24rpm
68.0N.M
RV075
80
18rpm
80.0N.M
RV075
100
14rpm
94.0N.M

0.37kw 1400rpm
RV075
40
35rpm
74.0N.M
RV075
50
28rpm
88.0N.M
RV075
60
24rpm
97.0N.M
RV075
80
18rpm
119.0N.M
RV075
100
14rpm
139.0N.M



0.55kw 1400rpm
RV075
25
56rpm
76.0N.M
RV075
30
47rpm
87.0N.M
RV075
40
35rpm
108.0N.M
RV075
50
28rpm
128.0N.M
RV075
60
24rpm
144.0N.M
RV075
80
18rpm
177.0N.M
RV075
100
14rpm
206.0N.M



0.75kw 1400rpm
RV075
15
94rpm
66.0N.M
RV075
20
70rpm
85.0N.M
RV075
25
56rpm
101.0N.M
RV075
30
47rpm
117.0N.M
RV075
40
35rpm
147.0N.M
RV075
50
28rpm
174.0N.M
RV075
60
24rpm
196.0N.M
RV075
80
18rpm
250.0N.M




1.1kw 1400rpm
RV075
10
140rpm
66.0N.M
RV075
15
94rpm
95.0N.M
RV075
20
70rpm
122.0N.M
RV075
25
56rpm
148.0N.M
RV075
30
47rpm
171.0N.M
RV075
40
35rpm
216.0N.M
RV075
50
28rpm
263.0N.M
RV075
60
24rpm
297.0N.M


1.5kw 1400rpm
RV075
7.5
186rpm
68.0N.M
RV075
10
140rpm
89.0N.M
RV075
15
94rpm
129.0N.M
RV075
20
70rpm
166.0N.M
RV075
25
56rpm
202.0N.M
RV075
30
47rpm
233.0N.M
RV075
40
35rpm
299.0N.M


2.2kw 1400rpm
RV075
7.5
186rpm
99.0N.M
RV075
10
140rpm
131.0N.M
RV075
15
94rpm
189.0N.M
RV075
20
70rpm
249.0N.M
RV075
25
56rpm
304.0N.M
RV075
30
47rpm
247.0N.M
3.0kw 1400rpm
RV075
7.5
186rpm
135.0N.M
RV075
10
140rpm
178.0N.M
RV075
15
94rpm
258.0N.M
4.0kw 1400rpm
RV075
7.5
186rpm
180.0N.M
RV075
10
140rpm
237.0N.M


Specification


Product name
RV075 worm gear speed reducer/worm gearbox
Ratio
7.5,10,15,20,25,30,40,50,60,80,100
Power
0.25~4.0 KW
Color
Blue/Silver/Black or on Request
Weight
9 Kg


Material
Housing : Aluminum alloy
The gear is made of carburized 20CrMnTi with good wear resistance and no noise
The wormwheel is Wheelhub cast iron QT500 and bronze ZQSn10-1
The wormshaft:steel 20Cr with a carburized surface and hardness of HRC60

Single unit input versions
SMRV : fitted for motor flanged coupling
SMRV-E : motor flanged coupling with worm extension shaft
SRV : with input shaft
SRV-E : with double extension worm shaft
Suitable motor pole
2pole,4pole,6pole
Inch size
Available
Personal customization
Available
Extra service
OEM
Quality Assurance
1 year



Features
High precision, stable transmission and large output torque.Also meens high quality, long service life.
There are many cooling fins to realize rapid heat dissipation
Suitable for omni-directional installation
Can be easily mounted with various accessories like torque arms, different types of flanges, shafts and so on
Good rust resistance


We produce speed reducers in strict accordance with ISO9001 standard to provide our customers with high quality gearboxes at competitive prices. Our gearboxes are equipped with accessories from international famous brands, such as oil seal from SKF brand,lubricant from Shell brand, and bearing from NSK brand. The housing and gear are produced in our company under stringent quality control. All our products are available in large stocks, and we can also provide you with customized reducer solutions, pleasefeel confident to contact us.








Taizhou Sihai Machinery Co., Ltd.
History: More than 20 years of experience in the manufacture of reducer products.Scale: Cover working area of 13300 square. meters,have more than 113 employees.
Technology: A group of professional . technical engineers and a strong R&D team.
Management: Scientific ERP management and strict quality control system.
Equipment: 50 CNC lathes,6 machining. centers, 6 gear grinding machines, 2 high-speed.hard hobbing machines, 12 gear hobbing
machines. 10 CNC cylindrical grinding machines,4 CNC internal grinding machines 1spectrometer, high-speed gear shaping 1 machine,
2 gear measuring centers 1 coordinate measuring instrument.
lnnovation: Continuously diversify products range to satisfy customers'needs.Production capacity: 1000 pcs/day.
Long-term supplier of world-class companies: t he main markets are in Southea st Asia, Europe, Middle East.
Marketing model: All export business.












FAQ


Q1:How to choose a speed reducer which meets our requirement?
A1:Tell me the motor information , or provide the motor related parameter drawings, or take some clear pictures of the motor and related equipment to me. I'm appreciated if you can tell me what type of reducer you used originally.

Q2:When is the best time to contact you?
Anytime, I will reply you as soon as possible.

Q3:What's the quality of your products?
A3:Quality is always the foundation of our company.I suggest you buy a sample to evaluate the quality.Taizhou Sihai Machinery Co.,Ltd.Engaged in research and development, design and production of reducer for more than 20 years.

Q4. Do you offer any visiting?
A4: Yes! Welcome!Notify me in advance.

Q5. How long will it take for the lead time?
A5: At the time we agreed
