China Factory Good Quality Oil Fuel Liquid Coriolis Mass Flow Meter for sale
- Category: Test Instruments >>>
- Supplier: Dalian,Metern,Measurement,And,Control,System,Co.,Ltd.
Share on:
Product Overview
Description
Oil Fuel Liquid Coriolis Mass Flow Meter for sale
Product Description
Metern MTCMF Coriolis mass flowmeters are the leading precision flow and density measurement solution
offering the mostaccurate and repeatable mass measurement for liquids, or slurries. MTCMF meters offer the most accurate measurement available for virtually any process fluid, while exhibiting exceptionally low
pressure drop.
Product Description
Technical Parameters
| Model | Nominal size(mm) | Flow rate(t/hr) | Zero stability(kg/hr) |
| MTCMF-003 | 3 | 0~0.15~0.18 | 0.18 |
| MTCMF-006 | 6 | 0~0.6~0.72 | 0.72 |
| MTCMF-008 | 8 | 0~0.96~1.2 | |
| MTCMF-010 | 10 | 0~1.8~2.1 | 0.21 |
| MTCMF-015 | 15 | 0~3.6~4.5 | 0.45 |
| MTCMF-020 | 20 | 0~6~7.2 | 0.72 |
| MTCMF-025 | 25 | 0~9.6~12 | 1.2 |
| MTCMF-032 | 32 | 0~18~21 | 2.1 |
| MTCMF-040 | 40 | 0~30~36 | 3.6 |
| MTCMF-050 | 50 | 0~48~60 | 6.0 |
| MTCMF-080 | 80 | 0~150~180 | 18 |
| MTCMF-100 | 100 | 0~240~280 | 28 |
| MTCMF-150 | 150 | 0~480~600 | 60 |
| Accuracy | ±0.2%, ±0.1% optional |
| Repeatability | ±0.1%~0.25% |
| Density measurement range | 0.5~2g/cm3, Accuracy: ±0.002 g/cm3 |
Operating temperature | -50~+200℃(standard), -200~+300℃ |
Ambient temperature | -20~+60℃ or -40~+60℃ |
Material | Measuring tube:SS316L, housing:SS304 |
Nominal pressure | 20 MPa |
Ex-proof | Exd (ia)ⅡC T6Gb |
| Display | Digital LCD local display |
| Display variable | Mass flow,volume flow,density,temperature |
| Ambient temperature | -20~60℃ |
| Output signal | Pulse+4-20mA+RS485 |
| Communication | Modbus/Hart |
| Power supply | 18~36VDC power≥7W;85~265VAC power 10W |
| Protection level | IP65 |
| EX-proof | Exd(ia)IICT6Gb |
Why Choosing us?
1. Product development and special customized ability for clients.
2. The independent intellectual property rights and the international certification authority.
3. We value every customer. Before delivery, we inspect the pens with our QC standard, so as to cont rol the attrition rate at the lowest.
4. As a professional manufacturer, we have a modern and developed production line to the prompt supp ly to every single client.
Production Line
International Exihibition
Certifications
Packaging & Shipping
Company Information
Be founded in 1998.
Registered capital: USD 10 million
Building area: 30000m2
Established R&D of Coriolis mass flow meter since 2005
Started production and sales of Coriolis mass flow meter since 2008
Products are exported to Italy, Spain, Belgium, Brazil, Colombia, Malaysia, ect.
