RK3399 2GB 16G Memory development board for developing

Hardware Index

CPU

RK3399(Dual Cortex-A72+Quad Cortex-A53)

ARM 64bit 1.8GHZ

GPU

Mali-T860MP4 GPU,support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11 support AFBC

RAM

DDR3  2G/4G (2G/4G optional)

ROM

eMMC   16GB(32G/64G optional)

Storage Extension

Max support 128GB TF Card extension

Network

Built-in Wi-Fi Module,support 2.4G/5G Wi-Fi ,support Wi-Fi 802.11b/g/n protocol

Support Blue-tooth,V2.1+EDR/Blue-tooth 3.0/3.0+HS/4.0BLE

Support 10/100/1000Gbps Ethernet,Support Ethernet

System

Operation System

Android 7.1

Rotation system

Support 0°,90°,180°270°Manual rotation,G-sensor Auto rotation(Optional)

Language

Simplified Chinese, Traditional Chinese, English, French, German, Italian, Japanese,

Korean, Russian, Spanish, Polish, Czech, etc multi-language

Internet Function

Browser

Support UC Web, Google, etc multi-browser

Online Entertainment

Supports online video, TV, movie, music and radio

Office Software

WORD, EXCEL, POWERPOINT, PDF, TXT

Game

Internal 3D speed up, perfect to supports 3D game

Expansibility

Can free download More 20,000 games in Google market

Video Playback

Format

Supports H.264,VP8,MAV,WMV,AVS,H.263,MPEG4 etc video format 1080P

decoding and online video,max up to 4K*2K

Decoding Resolution

Max Up to 3840*2160

Audio Playback

Format

Supports MP3,WMA,WAV,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WAV audio playback

Record Function

Supports MP3,WMA recording

Additional Function

Image Browsing

Supports JPG, BMP,PNG and GIF image browsing, image rotation and picaslide Lite;

Resolution is up to 4096*4096

Text Reading

Supports TXT,PDF,HTML,HTM,CHM,UMD

Basic Interface

USB2.0 Interface

5*USB-2.0 HOST , 1*USB3.0 OTG , 1*USB3.1Type_C

UART Extension

1*RS232 , 1*RS485 , 3*UART TTL

LVDS Output

LVDS/LVTTL*1 (Single Chanel,6bits Dual Chanel,8bits,10bits Dual Chanel),Max support resolution 3840*2160

EDP output

EDP*1 Max support resolution 3840*2160 4K*2k 30fps

LCD Backlight Interface

1*LVDS-BL power in, standard 6pin socket (DC-in 12V/5V/3V)

LCD Backlight Interface

1*LVDS-BL power in, standard 6pin socket

Voltage for LCD Backlight Interface

1*standard 3pin socket (DC-in 12V/5V)

HDMI Output

1*HDMI2.0 60fps 4K*2K display

MIPI Camera input

Embed 13M ISP and MIPI 4K Camera function(optional)

Headphone/Mic

One external headphone audio output and Mic input(standard:GNC,MIC,R,L)

Speaker Output

1*internal socket, maxi supports 2*10W/8Ω speaker(with 4Ω need to change

parameter)

MIC-In

1*Internal MIC

TF Card

One standard TF card slot(Max 128G)

LAN

RJ45 standard 100 MB interface

IR Head

IR (can be weld on master board or use with an extension cord)

RTC Real-Time Clock

One clock battery holder

Power Supply

One external socket and internal 6P socket(with STB feature), DC 12V input

Bi-Color LED

One internal bi-color LED light

Infrared Remote Receiver

One internal infrared remote receiver socket(can be welded on PCB or connected by

extension cord according to structure)

Button

One internal 6pin socket connected by extension wire

Touch panel socket

One internal 6P socket,provider I2C interface(support multi-RTP/CTP touch)

I/O socket

One internal 4P socket(supports GPIO*4 extension)

Other Functions

Touch Screen

Supports capacitive /resistive/infrared touch

Other Input Devices

Supports USB keyboard/mouse/IR remote

Voice Function

Supports

Video Function

Supports USB camera up to 8MP

System special feature

Watch dogs,Timing power on&off,remote control power on&off

Electrical Specifications

Power-In

Switching power supply(12V/3A

Consumption

<=2.5W, not connecting to speaker/LCD/backlight inverter/USB devices

Working Environment

Working Temperature

0℃~40℃

Working Humidity

 10%~90%, without condensation

Storage Temperature

-40℃~70℃,recommended 5℃~35℃
