2.4 inch wholesale TN 240*320 MCU/SPI/SPI RGB interface 45 pin tft lcd display panels
2.4 inch wholesale TN 240*320 MCU/SPI/SPI+RGB interface 45 pin tft lcd display panels
2.4 inch wholesale TN 240*320 MCU/SPI/SPI+RGB interface 45 pin tft lcd display panels
2.4 inch wholesale TN 240*320 MCU/SPI/SPI+RGB interface 45 pin tft lcd display panels
2.4 inch wholesale TN 240*320 MCU/SPI/SPI+RGB interface 45 pin tft lcd display panels
2.4 inch wholesale TN 240*320 MCU/SPI/SPI+RGB interface 45 pin tft lcd display panels

2.4 inch wholesale TN 240*320 MCU/SPI/SPI RGB interface 45 pin tft lcd display panels

Share on (1600456328709):


Price:$0.10

Quantity:


Product Overview

Description









Product Discription


name
2.4  inch LCD display
model
X240H005A0
size
2.4 inch
resolution
240*320
display type
TFT
display color
65K /262K
pixel pitch
0.153 (H) x 0.153 (V)
viewing direction
12 o'clock
controller IC
ST7789V
diasplay mode
Transmissive /Normally White
overall size
42.72*60.26*2.3 mm
active area
36.72*48.96mm
luminance
240 cd/m2
contrast
500:1
interface type
MCU/SPI/SPI+RGB
pin No.
45
backlight type and color
LED backlight / White
backlight
4LED Vled=3.3V Iled=60-80 mA
life span
50,000 hours
operating temperature
-20℃~70℃
storating temperature
-30℃~80℃
compliant
RoHs
certification
ISO:9001:2008
input voltage
3.0 v


Detail Images
