Product Overview
Description
Products Description
Machine model | CC-GM3015AH5 |
X*Y*Z Working area | 3000*15000*350 |
Saw axis Working area | A axis:0-90°；C axis:±360°；Infinite variable Angle |
Machine structure | Whole steel structure, segmented composite table, double bridge girder gantry structure, aging treatment |
Vacuum worktable | Vacuum negative pressure adsorption, multiple water cooling vacuum pump |
Auxiliary organization | T-slot, pneumatic positioning device, move the suction cup |
Control System | Taiwan Syntec 200MA (9 axis) control system |
Control cabinet | Independent control cabinet with forced cooling switch system |
Spindle brand | Taiwan mechanical water cooling spindle |
Spindle power/ speed | Spindle power 5.5KW, speed 0-10000rpm/min |
Spindle Tool holder | BT40 standard, hydraulic lock |
Tool magazine | Rotating-disk tool magazine, with 6 tools |
Saw blade motor | Italy Saw blade 7.5KW，speed 2800rpm/min |
Servo motor system | Japan YASKAWA servo motor and driver system |
Transmission | Imported square linear guide rail，XY precision rack gear drive，Z axis imported ball screw transmission |
Feed speed | X axis≥35000mm/min Y axis≥35000mm/min Z axis≥9000mm/min |
Position accuracy | ±0.1mm |
Re-position accuracy | ±0.05mm |
Total machine weight | About 12 tons |
Power/voltage/air pressure | Whole power 50KW voltage AC 380V/50HZ air pressure≥6.5Kgf/cm² |
Over dimensions | Wide*length*height：8000*15000*2500（mm） |
Auto oil feeding system | Yes |
Dust control system | Yes, moving type, anti-staticion wind rod dust removal system |
Safety protection | Yes CE switch, protective cover, emergency stop switch and so on |
Equipment lighting | Table lighting, work area clearly visible |
Company Profile
Shandong PEF Machine Tool Co.,Lted, was build in 2017, is one of the leading CNC solution experter in China. Providing a complete line of 5-Axis CNC Machine, Mold CNC Machining Center, CNC Router, Metal CNC Cutter, Composite Panle CNC Processing Center. For over 24 years, we have dedicated to providing one of the highest Quality-Cost-Ratio CNC machining solutions for the worldwide clients.With stable reliable product quality, reasonable price and high quality service, we won the praise of customers at home and abroad.
Why Choose Us
Team
1.Marketing department:Responsible for developing potential customers. Welcome to contact us if you are interested in 5 axis cnc center, cnc router, mold cnc center, RV composite panels process center, plasma cutting machine, fiber cutting machine,. We will provide best suggestions.
2.Sales department: Responsible for providing quotation, suggestion, replying question, delivering etc.
3.R&D department: Studying new function and model, upgrading the machinery parts and appearance, higher performance, higher humanize.
4.After-sale department: Helping customers resolve troubles, like how to use machine? how to operate the control system? how to design drawing?
2.Sales department: Responsible for providing quotation, suggestion, replying question, delivering etc.
3.R&D department: Studying new function and model, upgrading the machinery parts and appearance, higher performance, higher humanize.
4.After-sale department: Helping customers resolve troubles, like how to use machine? how to operate the control system? how to design drawing?
Service
1.Within 7day since your local customs clearance: if the cnc router’s any parts has any problems, we will change it for free.
2.Exceed 7 days since your local customs clearance but within 12 months warranty period: if there is any problem with cnc router, we can change the old machine parts to new ones for free without shipping cost.
3.Exceed warranty period: if the cnc router parts have any problems, we can offer new machine aprts with cost price and you also should pay all the shipping cost.
A.We offer 24 hours technical support by call and email;
B.Our technician can give you remote guide online (skyp or watsapp if you have any question.
C.We can record videos of operation the cnc machine, and provide free traning course in our factory.
D.Machine will be adjusted before it is delivered, operation Disk/CD was included.
2.Exceed 7 days since your local customs clearance but within 12 months warranty period: if there is any problem with cnc router, we can change the old machine parts to new ones for free without shipping cost.
3.Exceed warranty period: if the cnc router parts have any problems, we can offer new machine aprts with cost price and you also should pay all the shipping cost.
A.We offer 24 hours technical support by call and email;
B.Our technician can give you remote guide online (skyp or watsapp if you have any question.
C.We can record videos of operation the cnc machine, and provide free traning course in our factory.
D.Machine will be adjusted before it is delivered, operation Disk/CD was included.
Certification
We are Shandong Chencan Machinery Incorporated Company, the main products are 5 axis cnc center, cnc router, mold cnc center, RV composite panels process center, plasma cutting machine, fiber cutting machine etc.
We have many types certification for our machine, like CE Certificate for CNC Router, ISO 9001 international certificate, SGS certificate and BV certificate for our company etc.
Aside from this, the machine can be customized according to your requests, and there is Patent, Utility model patent certificate for our cnc router machine, and appled to Trademark Patent for Chencan.
Welcome to inquiry us and we provide best price and service for you!
We have many types certification for our machine, like CE Certificate for CNC Router, ISO 9001 international certificate, SGS certificate and BV certificate for our company etc.
Aside from this, the machine can be customized according to your requests, and there is Patent, Utility model patent certificate for our cnc router machine, and appled to Trademark Patent for Chencan.
Welcome to inquiry us and we provide best price and service for you!
Machining
1.We own kinds professional Professional R&D team, more than 20 engineer, could design and produce 5 axis cnc machine, RV composite panels processing center, big mold cnc center and other high-end custom cnc equipment.
2.Import USA HASS Vertical Machining Center, USA HASS Horizontal Machining Center, Taiwan AWEA Gantry Five-Face Machining Center, and own kinds of boring machine and milling machine. More than 20 years machining experience to ensure the quality and precision of all mechanical spare parts;
3.Use advanced testing equipment to test the cnc machine before delivery: We import UK RENISHAW brand laser interferometer / USA leader brand coordinate measuring machine / UK RENISHAW brand ballbar system, own Laser autocollimator / Optical edge finder Dial gauge, Dial indicator / square box / Marble square box and do insulation resistance text / ground resistance test / pressure test, to make sure all machine with the perfect performance before delivery.
Welcome to inquiry us and we provide best formula and service for you!
2.Import USA HASS Vertical Machining Center, USA HASS Horizontal Machining Center, Taiwan AWEA Gantry Five-Face Machining Center, and own kinds of boring machine and milling machine. More than 20 years machining experience to ensure the quality and precision of all mechanical spare parts;
3.Use advanced testing equipment to test the cnc machine before delivery: We import UK RENISHAW brand laser interferometer / USA leader brand coordinate measuring machine / UK RENISHAW brand ballbar system, own Laser autocollimator / Optical edge finder Dial gauge, Dial indicator / square box / Marble square box and do insulation resistance text / ground resistance test / pressure test, to make sure all machine with the perfect performance before delivery.
Welcome to inquiry us and we provide best formula and service for you!
Production Line
1. Prepare raw materials
2. Welding
3. Processing
4. Painting and sand blasting
5. Complete machine assembly
6. Inspection, assembly and commissioning process
7. Delivery
Exhibition
Customer Photos
FAQ
1,The first use of this machine, it is easy to operate?
---There are English manual or guide video that show how to use machine.If you still have any queation,we can talk from phone or whatsapp.even you can come to over factory to learn the machine.
2,If machine has any problem after I ordered it,how could I do ?
---Free parts send to you in machine warranty period if machine have any problem.
3,Free after-sales service time for machines?
---Please feel free contact us if your machine have any problem,we will give you 24 hours service from phone ,skype and whatsapp.
4,Payment
T/T (30% in advance, balance before delivery).
5.You are factory or trading company?
---We are factory,and we have Import and export rights also.
6.MOQ
---1 set.
---There are English manual or guide video that show how to use machine.If you still have any queation,we can talk from phone or whatsapp.even you can come to over factory to learn the machine.
2,If machine has any problem after I ordered it,how could I do ?
---Free parts send to you in machine warranty period if machine have any problem.
3,Free after-sales service time for machines?
---Please feel free contact us if your machine have any problem,we will give you 24 hours service from phone ,skype and whatsapp.
4,Payment
T/T (30% in advance, balance before delivery).
5.You are factory or trading company?
---We are factory,and we have Import and export rights also.
6.MOQ
---1 set.
