Intelligent irrigation fertilizer machine automatic fertilizer system multi purpose water and fertilizer machine
- Category: >>>
- Supplier: Myxl Greenhouse Tech And Dev Co. Ltd.
Share on (1600458515153):
Product Overview
Description
Intelligent irrigation fertilizer integrated multi-purpose water and fertilizer machine
Products Description
Bypass Fertilizer - A
With high cost performance, it is deeply loved by the majority of fieldgrowers. Thenewly designed operating system allows every user to completeirrigation and fertilization efficiently and safely through the most simple and intelligent operation.
With high cost performance, it is deeply loved by the majority of fieldgrowers. Thenewly designed operating system allows every user to completeirrigation and fertilization efficiently and safely through the most simple and intelligent operation.
Model | Bypass |
size | L911*W905*H1438mm |
weight | 75KG |
Rate | 2.2KW |
Power Supply | 380V,50HZ |
HMI | 10 inch capacitive display |
Frame | 304 Stainless steel |
EC/PH Sensor | Standard single channel EC/PH |
Fertilizer channel | 2 fertilizer 1 Acid（Standard）up to 4 channels |
Fertilizer injection capacity | 600/h/Channel |
Pipe | Sanli Chemical UPVC |
pipeline pressure | <6.0bar |
Rugged and Durable Upgraded Protection
As an agricultural production tool, sturdiness is extremely important. FISMART-A adopts 304 stainless steel material and robot welding process, with high overall structural strength, acid resistance and corrosion resistance
Precise fertilizer, intelligent perception, reliable production tools
Equipped with high-precision EC and PH sensors, accurate measurement. Through PWM modulation technology, the ratio of fertilizer intake can be perfectly controlled to ensure accurate fertilizer distribution.
Internet connection , support remote control
FISMART-A Support multiple ways of networking, WIFI/WAN/4G are available. Remote control through mobile app.
Fertilizer formula:
Support up to 5 formulas for users to edit, realize multi-purpose of one machine, different planting crop
Irrigation program:
Support 5 independent irrigation programs, which can be executed simultaneously or sequentially
Program start conditions:
Irrigation programs support timed start conditions
Valve grouping:
Support 5 valve groups, different valve groups can be added with different valves for irrigation sequence call
Abnormal alarm:
The system has a complete abnormal alarm mechanism, including low liquid level in the liquid storage tank, equipment network interruption, etc.
Log record:
The fertilizer applicator will save the operation record of the fertilizer mixing process and irrigation program for the user
analysis view
Liquid level detection:
up to 4 channels of liquid level detection. Need to expand the liquid level detection module
Program upgrade:
network automatic update or U disk one-key upgrade
Internet of Things function:
can be connected to mobile APP and computer software operation platform for remote control and parameter settings
Support up to 5 formulas for users to edit, realize multi-purpose of one machine, different planting crop
Irrigation program:
Support 5 independent irrigation programs, which can be executed simultaneously or sequentially
Program start conditions:
Irrigation programs support timed start conditions
Valve grouping:
Support 5 valve groups, different valve groups can be added with different valves for irrigation sequence call
Abnormal alarm:
The system has a complete abnormal alarm mechanism, including low liquid level in the liquid storage tank, equipment network interruption, etc.
Log record:
The fertilizer applicator will save the operation record of the fertilizer mixing process and irrigation program for the user
analysis view
Liquid level detection:
up to 4 channels of liquid level detection. Need to expand the liquid level detection module
Program upgrade:
network automatic update or U disk one-key upgrade
Internet of Things function:
can be connected to mobile APP and computer software operation platform for remote control and parameter settings
Packaging & Delivery
Step 1: Design greenhouse drawings and plans
Step 2: Pack the greenhouse covering materials in woven bags
Step 3: Provide an introduction to the greenhouse in English
Step 4: Check the waterproof index for suitable and practical packaging
Step 5: Communicate with logistics to check appropriate details
Step 6: Control the delivery of each line. According to customer requirements.
Step 2: Pack the greenhouse covering materials in woven bags
Step 3: Provide an introduction to the greenhouse in English
Step 4: Check the waterproof index for suitable and practical packaging
Step 5: Communicate with logistics to check appropriate details
Step 6: Control the delivery of each line. According to customer requirements.
Company Profile
FAQ
1. Determine the planting crops
Different crops have different growth characteristics and different irrigation schemes. Therefore, clearly planting crops is a prerequisite for rationally configuring an irrigation system, and it is also an important reference factor for judging whether an irrigation system is reasonable.
2. Use soil cultivation or soilless cultivation
Whether soil cultivation or soilless cultivation is adopted may affect the amount and frequency of irrigation of crops, which must be taken into account in the calculation of irrigation system.
3. Determine the type of irrigation
The specific selection of sprinklers, sprinkler trucks or drip arrows to irrigate crops requires full consideration of the types and growth periods of crops.
4. Determine the layout of the entire system
Determine the number of solenoid valves, the flow rate of each solenoid valve area, and the end working pressure.
5. Installation, commissioning and after-sales service of irrigation and fertilizer applicators
During the installation of electrical or PVC pipes, we can provide technical support by remote means such as telephone.
