High Quality Membrane Electrolysis Technology HCIO water ionizer / Hypochlorous acid generator
- Category: >>>
- Supplier: Zhangjiagang Aqua Machinery Co. Ltd.
Share on (1600459346231):
Product Overview
Description
Product Overview
High Quality Membrane Electrolysis Technology HCIO water ionizer / Hypochlorous acid generator
1/ The device can fully electrolyze the chloride ion in an aqueous solution to produce the most efficient bactericidal component,
hypochlorous acid HCIO, which does not produce ozone or oxygen, does not produce chlorine, high chloride chloride HCIO2, HCIO3,
etc.
2. Slightly acidic electrolyzed water is also called Chlorochloric acid, pH 5.0-6.5, effective concentration is usually 10-30ppm,
can also be adjusted according to needs, the highest concentration can reach 30,000ppm.
3. In Japan, where food safety standards are extremely high, in 2002, the Ministry of Health, Labor and Welfare of Japan approved
micro-acidic electrolyzed water as a bactericidal ingredient for food additives, officially known as hypo-acid water. Used for
cleaning, sterilization and fresh-keeping of food materials
4. Non-corrosive, humidifying spray, improving air quality, effectively preventing epidemic diseases
5.Non-irritating, no heavy metal, household care can be used for tableware disinfection, personal wound disinfection
6. Low concentration and high activity, the bactericidal ability is 80 times that of sodium hypochlorite. It can be used for
slaughtering, aquatic products, fruit and vegetable sterilization and ice making.
7.Non-toxic, sterile and quick to produce, low cost, used in the fungus industry for aseptic vaccination
8. High concentration of hypochlorous acid water, strong oxidizing, can be used in various types of sewage treatment
hypochlorous acid HCIO, which does not produce ozone or oxygen, does not produce chlorine, high chloride chloride HCIO2, HCIO3,
etc.
2. Slightly acidic electrolyzed water is also called Chlorochloric acid, pH 5.0-6.5, effective concentration is usually 10-30ppm,
can also be adjusted according to needs, the highest concentration can reach 30,000ppm.
3. In Japan, where food safety standards are extremely high, in 2002, the Ministry of Health, Labor and Welfare of Japan approved
micro-acidic electrolyzed water as a bactericidal ingredient for food additives, officially known as hypo-acid water. Used for
cleaning, sterilization and fresh-keeping of food materials
4. Non-corrosive, humidifying spray, improving air quality, effectively preventing epidemic diseases
5.Non-irritating, no heavy metal, household care can be used for tableware disinfection, personal wound disinfection
6. Low concentration and high activity, the bactericidal ability is 80 times that of sodium hypochlorite. It can be used for
slaughtering, aquatic products, fruit and vegetable sterilization and ice making.
7.Non-toxic, sterile and quick to produce, low cost, used in the fungus industry for aseptic vaccination
8. High concentration of hypochlorous acid water, strong oxidizing, can be used in various types of sewage treatment
FEATURES AT A GLANCE
1/ Our Hypochlorous Acid Water Generator is a industrial type not commercial or Household
2/the electrolyte is Nacl or HCL,Different machine .
3/ Small capacity is 100LPH
4/Inlet water required RO water
PRODUCT SPECIFICATIONS
Product Name | High Quality Membrane Electrolysis Technology HCIO water ionizer / Hypochlorous acid generator |
Inflow pressure : | 0.05~0.15MPa |
Power supply: | 380v 50HZ 3 Phase |
Outflow rate: | Smallest 60L/H |
Productive way: | continuous electrolysis |
pH value: | 5.5-6.5 Adjustment |
The volume of effective chlorine | 10-30000PPM (Depends on Customers) |
Power | 3 KW |
Weight | 300KG |
Machine size | 1200*1600*500MM（L*H*W） |
Inelt water requirement | RO water |
Electrolyte | Nacl or Hcl |
PRODUCT CONFIGURATION
Item | Main Component | Brand |
System function | Brief | Industrial-grade equipment can run 24 hours a day without interruption, automatic alarm and shutdown when there is insufficient raw water, acid or alkali water full. Key indicators such as pH value are displayed in real time through online meters. |
Electrical and Automation Control | Breaker | ABB |
AC contactor | ABB | |
VFD | ABB | |
PLC | Siemens | |
Touch screen | Siemens | |
Terminals | PHOENIX | |
Cable | LAPP | |
Level Switch | Taiwan Radar | |
Electrolysis device | Electrolyze | Titanium platinum alloy plate (Our Patent) |
Electrolytic power supply | Customized military grade | |
Waterway valve | Stainless steel valve | 304 Stainless steel(Shangdong Public company) |
UPVC pipes | Food grade，Fromosa Plastics(top company from Taiwan) | |
Online meter | Inlet conductivity | Create From China(Public Company) |
Outlet pH | Create From China(Public Company) | |
Dosing system | Dosing pump | SEKO From Italy |
box | PE | |
Control cabinet | 304 stainless steel | Aqua |
Water treatment cabinet | 304 stainless steel | Aqua |
Successful Project
Project in South Korea
Project in China
one of the biggest water supplier
Project in indonesia
Application
Food Industrial
There are a lot of pesticide residues in vegetables and fruits. The use of alkaline water can effectively remove these residues. At the same time, alkaline electrolyzed water is harmless to the food itself.
Food industrial
Marine product storage and preservation
Cleaning of Marine product processing equipment and utensils
Breeding environment and utensil disinfection
Livestock drinking water.
Slightly acidic electrolyzed water is pumped into the pipeline and directly used by livestock and poultry, which can effectively play a role in disinfection and sterilization.
Restaurants and Feeding Industry
Strongly electrolyzed water can kill all kinds of bacterial such as E.coil. Staphylococcus aureus, salmonella,vibrio parahaemolyticus and etc,
Medical instrument
you can sterilize many kinds of bacterial on the surface of medical tools and prevent infection from the tools
Restaurants / feeding facilities
It solves the hygiene problems in the slaughter house by sterilizing floor and facilities and deodorizing smells of blood and rotten meats
SIMILAR PRODUCTS
Alkaline water ionizer Machine
1/ PH 7-10 drinking Alkaline water
2/ 1000LPH smallest production
3/ To making drinking Alkaline water with safe technology, doesn't add any chemical to Adjust PH , only by ionizer
Hydrogen rich ionizer machine
1/ to make hydrogen water, Dual-core electrolysis
2/PH 7-10 Ajustment
3/OPR depends on customer
4/Hydrogen content normally 1.2-1.6ppm, but we can customize.
Strong Acid / alkaline machine
1. to make PH 12-14 Alkaline water
2. Function: Used to clean food, industrial, sterilize,agriculture ,medical etc.
FAQ
Q1：Why Choose US
A1: We made the industrial type alkaline water ionizer machine.the quality is the top in ionizer industrial. We do not need more maintenance cost, cause our machine is very stable.
Q2: Why your price is higher than others ?
A2: At first pls check the appearance of our machine, we are industrial type not commercial or household, our machine stability, life time, technology, configuration of the machine are not in the same level.
Q3: You also mentioned that you are the industrial Type not Commercial type, what is that meaning ?
A3: commercial type equipment with lost cost, so it can be accepted by people in the market, like the air conditioner, it is necessary for each family, but we only used a quarter of a year ; Likes the air conditioner in the supermarket, it will be used 80% in a year. Alternate use of cooling and heating modes, so the parts in side required high level, the life time should be longer, the quality should better, and required higher stability, Cause market is a public place, it is very important for them, but if you used a household machine into commercial usage, it will be broken soon, and the efficient is lower.
