1kw low frequency bipolar pulse power supply, Dc Voltage Regulators, stabilizer, protector

No

Item

Data

1

Product  type

Wt2-1kw low frequency bipolar pulse power supply

2

Product model

Wt2-1kw

3

Input voltage

AC220V±10%

4

Output power

1KW

5

Output current

1 ~ 100A (series parameters)

6

Output voltage

10 ~ 1KV (series parameters)

7

Output frequency  and Duty cycle

 1~255hz   1~99%

8

Output wave form andmode

Square wave, customizable: trapezoidal wave, triangular wave, sawtooth wave, sine wave, etc

9

Adjustment accuracy

≤1%

10

Efficiency

≥90%

11

Energy storage capacitance:

cosΦ≥0.9

12

Display mode

En +Cn

13

Ambient temperature

-35～+45℃

14

Ambient humidity

≤85%

15

Cooling mode

Air cooling

16

Overall dimension

400*95*370（mm ）

17

Installation dimension

18

Applicable fields

It is used in magnetic field scanning, sewage treatment, electron beam scanning, plasma scanning, etc

19

Product features

Flexible adjustment, pulse frequency, pulse current, pulse waveform, duty cycle and other parameters can be adjusted Small volume,light weight, simple structure, simple operation, stability and reliability The circuit adopts modular design, which is convenient
for debugging and maintenance.
