Alloy load cells 1000kg
- Category: >>>
- Supplier: Guangdong South China Sea Electronic Measuring Technology Co. Ltd.
Share on (1600462099775):
Product Overview
Description
Rated load (kg):30,50,60,100,150,200,250,300,350,500
Main features:The product is made of alloy aluminum. It is hermetically sealed with glue to IP65, surface anodized and anti-corrosion, integral structure and easy installation. The product is suit for electronic top scale, floor scale and other weighing equipment.
Parameters: | ||
Precision : C2/C3 | Temp. effect on span(%F.S/10°C): ±0.02/±0.014 | |
Comprehensive error(%F.S) : ±0.02/±0.017 | Temp. effect on zero(%F.S/10°C) : ±0.03/±0.017 | |
Rated output(mv/v) : 2.0±0.2 | Compensated temp. range(°C ) : -10~+40 | |
Creep(%F.S/30min) : ±0.02/±0.017 | Use temp. range(°C ) : -20~+60 | |
Zero balance(%F.S) : ±1.0 | Excitation voltage(V) : 9~12(DC) | |
Input resistance(Ω) : 405±10 | Safe overload (%F.S) : 120 | |
Output resistance(Ω) : 350±3 | Ultimate overload (%F.S) : 150 | |
Insulation resistance(MΩ) : ≥5000(100VDC) | Defend grade : IP65 | |
