Manufacture Plastic Toy Powerpicc Influvac Baseboard Connector Injection Plastique Injection Molding Machine
- Category: Injection Molding Machine >>>
- Supplier: Zhangjiagang,Shen,Zhou,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Application scenarios
Customized
ITEM | UNIT | SZ—2000A | ||
INJECTION UNIT | ||||
SCREW DIAMETER | mm | 50 | 55 | 60 |
SCREW LID RATIO | L/D | 23.1 | 21 | 19.3 |
THEORETICAL SHOT VOLUME | CM3 | 491 | 594 | 707 |
SHOT WEIGHT(PS) | g | 447 | 540 | 643 |
INJECTION PRESSURE | Mpa | 215 | 178 | 149 |
THEORETICAL INJECTION RATE(PS) | g/s | 145 | 175 | 208 |
PLASTICISING CAPACITY | g/s | 22.5 | 28.7 | 35.4 |
SCREW TORQUE | N.m | 1510 | ||
MAX.SCREW ROTATE SPEED | r/min | 170 | ||
INJECTION STROKE | mm | 250 | ||
CLAMPING UNIT | ||||
MAX.CLAMPING FORCE K | KN | 2000 | ||
MAX.OPENING STROKE | mm | 500 | ||
SPACE BETWEEN TIE BARS | mm | 505×505 | ||
MOULD HEIGHT | mm | 190-530 | ||
MAX.DAYLIGHT | mm | 1030 | ||
EJECTOR FORCE | KN | 53.1 | ||
EJECTOR STROKE | mm | 125 | ||
EJECTOR QUANTITY |
| 5 | ||
OTHER |
| |||
PUMP MOTOR POWER | KW | 18.5 | ||
PUMP PRESSURE | Mpa | 16 | ||
HEATING POWER | KW | 16.6 | ||
HEATING ZONE |
| 4 | ||
SIZE | m | 5.9×1.5×2 | ||
NET WEIGHT | t | 6.8 | ||
OIL TANK CAPACITY | L | 420 | ||
CERTIFICATE
Packaging & Shipping
COMPANY INFORMATION
FAQ
1Q.Do you have an entity factory?
A1 Yes,We are a factory integrating industry and trade and have a whole set of production process.
Q2.How long is our delivery period?
A2 Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery time of standard machine could be within 1-2 month.
Q3.What is the price of your injection molding machine?
A3 Our cost-effective performance is very high, the original parts of the machine are imported, wear-resistant, heat-resistant, high ductility.
Q4.How ahout your after-sales service?
A4 Our machines are guaranteed for life, if conditions permit, we will send engineers to overhaul.
