IC chip ATMEGA32A MU 32KB Microcontrollers ATMEGA32A MU
- Category: >>>
- Supplier: Guangzhou Liye Engineering Co. Ltd.
Share on (1600462934801):
Product Overview
Description
Product Description
ATMEGA32A ATMEGA32A-MU 32KB Microcontrollers
* Manufacturer Part Number:ATMEGA32A-MU
* Pbfree Code: Yes
* Rohs Code: Yes
* Part Life Cycle Code:Active
* Package Description:VQFN-44
* Reach Compliance Code:compliant
* Samacsys Description:ATMEGA32A-MU, 8 bit AVR Microcontroller 16MHz 32, 1024kB, B Flash, 2kb RAM, I2C SPI 44-Pin VQFN
* Has ADC:YES
* Additional Feature:ALSO OPERATES AT 2.7 V MINIMUM SUPPY AT 8 MHZ
* Bit Size:8
* CPU Family:AVR RISC
* Clock Frequency-Max:16 MHz
* DAC Channels:NO
* DMA Channels:NO
* JESD-30 Code:S-PQCC-N44
* Length:7 mm
* Number of I/O Lines:32
* Number of Terminals:44
* Operating Temperature-Max:85 °C
* Operating Temperature-Min:-40 °C
* PWM Channels:YES
* Package Body Material:PLASTIC/EPOXY
* Package Code:HVQCCN
* Package Equivalence Code:LCC44,.28SQ,20
* Package Shape:SQUARE
* Package Style:CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
* Power Supplies:3/5 V
* Qualification Status:Not Qualified
* RAM (bytes):2048
* ROM (words):16384
* ROM Programmability:FLASH
* Seated Height-Max:1 mm
* Speed:16 MHz
* Subcategory:Microcontrollers
* Supply Current-Max:15 mA
* Supply Voltage-Max:5.5 V
* Supply Voltage-Min:4.5 V
* Supply Voltage-Nom:5 V
* Surface Mount:YES
* Technology:CMOS
* Temperature Grade:INDUSTRIAL
* Terminal Form:NO LEAD
* Terminal Pitch:0.5 mm
* Terminal Position:QUAD
* Width:7 mm
* uPs/uCs/Peripheral ICs Type:MICROCONTROLLER, RISC
* Manufacturer Part Number:ATMEGA32A-MU
* Pbfree Code: Yes
* Rohs Code: Yes
* Part Life Cycle Code:Active
* Package Description:VQFN-44
* Reach Compliance Code:compliant
* Samacsys Description:ATMEGA32A-MU, 8 bit AVR Microcontroller 16MHz 32, 1024kB, B Flash, 2kb RAM, I2C SPI 44-Pin VQFN
* Has ADC:YES
* Additional Feature:ALSO OPERATES AT 2.7 V MINIMUM SUPPY AT 8 MHZ
* Bit Size:8
* CPU Family:AVR RISC
* Clock Frequency-Max:16 MHz
* DAC Channels:NO
* DMA Channels:NO
* JESD-30 Code:S-PQCC-N44
* Length:7 mm
* Number of I/O Lines:32
* Number of Terminals:44
* Operating Temperature-Max:85 °C
* Operating Temperature-Min:-40 °C
* PWM Channels:YES
* Package Body Material:PLASTIC/EPOXY
* Package Code:HVQCCN
* Package Equivalence Code:LCC44,.28SQ,20
* Package Shape:SQUARE
* Package Style:CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
* Power Supplies:3/5 V
* Qualification Status:Not Qualified
* RAM (bytes):2048
* ROM (words):16384
* ROM Programmability:FLASH
* Seated Height-Max:1 mm
* Speed:16 MHz
* Subcategory:Microcontrollers
* Supply Current-Max:15 mA
* Supply Voltage-Max:5.5 V
* Supply Voltage-Min:4.5 V
* Supply Voltage-Nom:5 V
* Surface Mount:YES
* Technology:CMOS
* Temperature Grade:INDUSTRIAL
* Terminal Form:NO LEAD
* Terminal Pitch:0.5 mm
* Terminal Position:QUAD
* Width:7 mm
* uPs/uCs/Peripheral ICs Type:MICROCONTROLLER, RISC
Specification
item | value |
Model Number | ATMEGA32A-MU |
Type | Microcontrollers |
Place of Origin | China |
Guangdong | |
Brand Name | Original Brand |
D/C | Newest |
Package | QFN44 |
Operating Temperature | -40℃ ~ 85℃ |
Mounting Type | Surface Mount |
Package / Case | QFN44 |
Supply Voltage (DC) | 2.70V (min) |
Clock Speed | 16.0 MHz |
RAM Memory Size | 2 KB |
FLASH Memory Size | 32768 B |
Number of ADCs | 1 |
Number of Inputs and Outputs | 32 Input |
Packaging | Each |
