48 Volt Lifepo4 Lithium Ion Solar Battery 100ah 5kwh Lithium Battery Pack for Home Energy Storage
- Category: >>>
- Supplier: Shenzhen Willys Energy Co. Ltd.
Share on (1600463042065):
Product Overview
Description
Product Description
48 Volt Lifepo4 Lithium Ion Solar Battery 100Ah 5kwh Lithium Battery Pack for Home Energy Storage
Features:
| The battery module consists of single LFP cells, wire, BMS and metal container. |
| • LFP single cell, long life, safety and wide temperature range; |
| • High energy density, small size, light weight, no pollution; |
| • High efficiency, fast charging; |
| • Built-in BMS, protect voltage, current, temperature in whole service life; |
| • Integrated communication interface, communication with inverter controller; |
| • Integrated LED indicator, display the SOC and operating status; |
| • Standardized module, supporting parallel design, matching a variety of inverters; |
| • 15 years design life, stable performance, maintenance-free. |
Specification:
| Model | VHES3000A | VHES3000B | VHES5000A | VHES5000B |
| Basic | ||||
| Rated Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Rated Capacity (0.2C, @25°C) | 60Ah | 60Ah | 100Ah | 100Ah |
| Rated Energy | 3.072KWh | 3.072KWh | 5.12KWh | 5.12KWh |
| Operating | ||||
| Output Voltage Range | 44.8V-56V | 44.8V-56V | 44.8V-56V | 44.8V-56V |
| Charging Voltage | 55.2-56.8V | 55.2-56.8V | 55.2-56.8V | 55.2-56.8V |
| Cut-off Voltage | 44.8V | 44.8V | 44.8V | 44.8V |
| Max. Charging Current | 60Ah | 60Ah | 100A | 100A |
| Recommended Charging Current | ≤30A | ≤30A | ≤50A | ≤50A |
| Max. Discharging Current | 70A | 70A | 100A | 100A |
| Physical | ||||
| Dimention L*W*H (mm) | 442*430*88 | 400*530*120 | 442*470*154 | 400*550*178 |
| Rack-mounted | Wall-mounted | Rack-mounted | Wall-mounted | |
| Weight (Kg) | 30 | 30 | 46 | 49 |
| Communication Port | RS485,CAN | RS485,CAN | RS485,CAN | RS485,CAN |
| Indicator | LED | LED+LCD | LED | LED+LCD |
| Terminal | M6 | Plug-in | M6 | Plug-in |
| Case Material | Metal | Metal | Metal | Metal |
| Environment | ||||
| Humidity | 5%-95% Relative Humidity | |||
| Charging Temperature Range | 0℃-45℃ | |||
| Discharging Temperature Range | -20-60℃ | |||
| Storage Temperature Range | -20-45℃ | |||
| Service Life | ||||
| Cycle Life >6000 times ( 0.5C , @25°C , 80%DOD ) | ||||
| Design Life >15 years |
Product Images
| Quality Contral: |
| 1.100% pre-tested for each product before shipping |
| 2. Specialized manufacturer with over 10-years experience |
| 3.Excellent customer service and technical support |
| 4. Strict quality control system and professional R&D team |
About LiFePO4
Company Profile
Packaging & Shipping
Packaging & Shipping
FAQ
Q1: What are there included for a battery or pack, may I buy charger from you?
A1: Battery case, BMS, battery pack, can buy customzied connector, charger.
Q2: How long frequency does recharge the battery?
A2: Usually per 2 months to recharge the battery pack , to charge full the battery depends on the charger
current you use. 20A charger can charge full for 12V 100Ah battery in 5 hours, fast charger 50A in 2 hours.
Q3: What's the sample lead time, and bulk order delivery. How long I can get it?
A3: Fast delivery: If small quantity, can be finished in 3-5 days days after payement, bulk in 10-25 days depends on the quantity.
Shipping: sample order or small battery packs, we can ship by express through Fedex, UPS, TNT etc. If whole parcel over 50KG, can ship by air or by sea, sea shipping is more cheaper. Customer can tell your nearest airport name and sea port name for sales person to check the best option for you.
Q4. What is your warranty?
A4: We offer 1-5 years warranty for all our battery pack for different situation. We ensure at least 3000 cycle life for the LiFePO4 battery pack, which means, after 3000@80% DOD, there will still around 60% capacityt left. You can use it for at least 10 years for normal 1 time charge and discharge everyday.
Q5: Can I customize the size of battery?
A5: Of course yes if yourquantity MOQ workable.
Q6: Can you print my logo on the battery cover?
A: Yes, OEM is available,we can print your logo on the battery case freely. Welcome to send us your logo design and dicuss with us about the details.
Q7: How’s the package?
A7: Normally are cartons, but also we can pack it according to your requirements.
Q8. Can we put different LiFePO4 battery pack in parallel or series by ourself?
A8: Yes. The battery can be put in parallel or series by customers. But there are few tips we need to pay attention;
1> Make sure the voltage of each battery are same before put inparallel. If they are not same, charge them to the same rate.
2> Don't not put discharged battery and undischarged battery in parallel. This may reduce the capacity of the whole battery pack.
3> Advise us the target capacity of the whole pack if you would like to put them in series. We will choose the suitable BMS for each battery.
4> If you are not professional in parallel and series batteries, please don't handle the battery by yourself. It may cause danger and hurt the cycle life of battery.
Q9. Can we use it for car engine?
A9: Yes, our battery pack include BMS, you can use it for low speed car only or aux. power for standard car. Do not use it for standard car directly, that will need more complex design BMS for the pack.
