  • 10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display
10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display

10.1 inch original factory supplying IPS DSI MIPI 4L interface JD9365DA tft lcd display

Share on (1600463524650):


Price:$0.10

Quantity:


Product Overview

Description







Product Discription




name
10.1  inch LCD display
model
XMZ101BI034A0
size
10.1 inch
resolution
800x1280
display type
TFT
display color
16.7M
Pixel Pitch
0.1692 (H) x 0.1692 (V)
viewing direction
ALL
controller IC
JD9365DA
diasplay mode
Transmissive /Normally Black
overall size
143.00*228.50*2.6 mm
active area
135.36*216.576mm
luminance
500 cd/m2
contrast
500:1
interface type
DSI MIPI 4L
pin No.
40
backlight type and color
LED backlight / White
backlight
32LED Vled=12V Iled=160 mA
life span
50,000 hours
operating temperature
-20℃~70℃
storating temperature
-30℃~80℃
compliant
RoHs
certification
ISO:9001:2008
input voltage
3.0 V


Detail Images
