  • 10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter
10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter

10KW 96Vdc PWM 50A/100A low Frequency Pure Sine Wave Solar Inverter 10000W Power Inverter

Share on (1600463842267):


Price:$1,093.00 - $1,150.00

Quantity:


Product Overview

Description



Our Advantages


Honest marketing
1.we are manufacturer with production experience for more than 10 years
2.We own ISO,CE,ROHS,FCC,ETL,PSE certificates
3.We accept OEM and ODM
4.Our salesman is with rich experience in foreign trade and efficient work efficiency
5.High-quality after-sales service to solve all your doubts


Product Paramenters


Model
SGN-10K/192
SGN-12K/192
SGN-15K/240
SGN-20K/240
SGN-25K
SGN-30K
SGN-40K
Rated Power
10KW
12KW
15KW
20KW
25KW
30KW
40KW
Input Voltage
96V/192V
96V/192V
192V/240V
192V/240V
240V
240V
384V
Solar Charge Controller
50A/100A(PWM)
50A/100A/150A/200A(PWM)
Packing Size (L*W*Hmm)
550*365*785
665*365*830
790*505*1260
Gross Weight (kg)
77
115
121
130
136
150
180
General Technical
Input
Input AC Voltage
73VAC~138VAC / 145VAC~275VAC(350W~7000W);
98VAC~125VAC / 195VAC~250VAC(8KW~40KW)
Ouput
Ouput AC Voltage
110VAC±2% / 220VAC±2%( Battery Mode)
Output Wave Form
Pure Sine Wave
Transfer Time
≤4ms
Efficiency
≥85%
Working Mode
Battery First/AC First/Saving Energy Mode
AC Charging Current
15A Max 15A
Inside Solar controller
(Optional)
Charging Mode
PWM / MPPT
Charging Current
12V/24V/48V(system): 10A,20A,30A,40A,50A,60A;
96V/192V/240V/384V(system): 50A,100A,150A,200A
PV Input Voltage Range
12V(system):15V-44V;
24V(system):30V-44V;
48V(system):60V-88V;
96V(system):120V-176V;
192V(system):240V-352V;
240V(system):300V-440V;
384V(system):480V-704V
Communication
RS232( optional)
Protection
Over-load / Over-discharge / Short circuit / High temperayure / Over-voltage / Low-voltage


Products Description






Recommend Products






Company Profile




Production workshop








FAQ


Q:Are you a directly factory or trading company?
A:We are inverter manufacturer.

Q: How does your factory do regarding quality control?
A: Quality is the priority. We always attach great importance to quality
controlling from the start to the end. All our products have gained CE, FCC, ROHS certification.

Q:What can you do?
A:1.AII of our products have proceeded aging test before shipment and we guarantee safety while using our products.
2. OEM/ODM orders are warmly welcomed!

Q:Warranty and return:
A:1. Products have been tested by 48hours continuous load aging before ship out.wanrranty is 2 years
2. We own the best after-sale service team, if any problem happens, our team will do our best to solve it for you.

Q:Is sample available and free?
A:Sample is available, but the sample cost should be pay by you. The cost of sample will be refund after further order.

Q:Do you accept customized order?
A:Yes, we do.

Q:What's the delivery time?
A:It usually takes 7-20 days after confirming payment, but specific time should be based on tne order quantity.
