DIY 30/28/26/24/22/20/18awg high quality flexible silicone wire cable 5 colors mix wire tinned Electrical Wire pure Copper Line

Product Overview

Description

DIY 30/28/26/24/22/20/18awg high quality flexible silicone wire cable 5 colors mix wire tinned Electrical Wire pure Copper Line



Color:   Red/Green/Blue/Yellow/Black
Length: 30 AWG  each roll 20 meters / total 100 meters
28 AWG  each roll 15 meters / total 75 meters
26 AWG  each roll 10 meters / total 50 meters
24 AWG  each roll 8 meters / total 40 meters
22 AWG  each roll 10 meters / total 50 meters
20 AWG  each roll 6 meters / total 30 meters
18 AWG  each roll 4 meters / total 20 meters
Type:   30/28/26/24/22/20/18 AWG Soft high temperature silicone wire
Rated voltage:600V
Temperature range:-60°C~+200°C
Country/Region of Manufacture:China
Insulation:Flexible Silicone Rubber
Applications:RC, Remote Control, Electronic, Battery Cable.etc
Strand diameter:0.08mm
Conductor Material:Tinned Copper
Size range:18/20/22/24/26/28/30AWG
Conductor Type:Stranded Copper
Our super-flexible silicone wire has virtually an unlimited number of uses!
Very suitable for various DIY electrical and hobby projects! The highly durable tinned copper wire has a durable environmentally friendly silicone sheath, high temperature resistance of 200°, and cold resistance of -60°.
It's  perfect for all kinds of DIY electrical and hobby projects! Featuring a durable  silicone jacket, this highly stranded tinned copper wire is a great alternative to more rigid PVC coated wire.

Flexible silicone wire 18 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 150 strands (0.75 square mm)
Outer diameter: 2.3mm

Flexible silicone wire 20 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 100 strands (0.5 square mm)
Outer diameter: 1.80mm

Flexible silicone wire 22 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Grain: 60 strands (0.3 mm2)
Outer diameter: 1.70mm

Flexible silicone wire 24 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 40 strands (0.2 mm2)
Outer diameter: 1.60mm

Flexible silicone wire 26 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 30 strands (0.15 mm2)
Outer diameter: 1.5mm

Flexible silicone wire 28 AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 16 strands (0.08 square mm)
Outer diameter: 1.3mm

Soft silicone wire 30AWG
Temperature: -60 degrees to 200 degrees-
Diameter of each copper wire: 0.08mm
Core: 11 strands (0.06 square mm)
Outer diameter: 0.8mm
