10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007 EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd
10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007+EK73215 tft display lcd

10.1 inch high quality TN 1024*600 DSI MIPI 4L interface EK79007 EK73215 tft display lcd

Share on (1600464467707):


Price:$0.10

Quantity:


Product Overview

Description







Product Discription




name
10.1  inch LCD display
model
XMZ101B032A0
size
10.1 inch
resolution
1024*(RGB)*600
display type
TFT
display color
16.7M
input voltage
2.8-3.3 V
viewing direction
6 o'clock
controller IC
EK79007+EK73215
diasplay mode
Transmissive /Normally White
overall size
235*143*5.1mm
active area
222.72*125.28*1.0mm
luminance
500 cd/m²
contrast
500:1
interface type
DSI MIPI 4L
pin No.
30
backlight type and color
LED backlight / White
backlight
42LED Vled=9-9.6V Iled=280mA
life span
50,000 hours
operating temperature
-20℃~70℃
storating temperature
-30℃~80℃
compliant
RoHs
certification
ISO:9001:2008
Pin Pitch
0.5 Pitch


Detail Images
