Product Overview
Description
Products Description
Specification | ||||||||
Machine type | Van type stainless steel filter press Specially, the filter cloth is embedded into filter plate. | |||||||
Filtration area | 80m2 | |||||||
Filter chamber volume (cake volume) | 1.22m3 | |||||||
Processing capacity (Production speed of filter cake) | 0.6m3/h | |||||||
Number of filter plate | 50 | |||||||
Size of filter plate | 1000*1000*60mm | |||||||
Thickness of cake | 30mm | |||||||
Filtration pressure | 1.0MPa | |||||||
Filtration temperature | 0~90 ℃ | |||||||
Voltage | 3ph-380V-50Hz, 3ph-415V-50Hz, 3ph-440V-60Hz, & as required | |||||||
Electric power | 4kW | |||||||
Certification | CE, ISO9000, ISO14000, National high-tech enterprise | |||||||
Colour | Grey,blue,yellow,green,white,customized | |||||||
After-sales service | Engineers available to service overseas | |||||||
Power type | Automatic hydraulic √ | Manual | ||||||
Cloth is embedded into plate | Yes √ | No | ||||||
Washing cloth automatically | Yes | No √ | ||||||
Machine body is stainless steel | Main girder is stainless steel 304 | The whole machine is SUS 304 √ | No | |||||
Filter plate shifting style | Auto shifting one by one | Auto shifting several by several | Manual shifting one by one √ | |||||
Diaphragm squeezing mode | PP diaphragm | Rubber diaphragm | Without √ | |||||
Drip tray | PP | Carbon steel | Stainless steel | Without √ | ||||
Application field
This filter press is applied in chemical industries.
Product description
Filter press is a machine for solid-liquid separation.The target product can be solid,can be liquid, also meanwhile can be solid and liquid.The working process of filter press includes the following: 1. Compressing filter plates 2. Feeding target liquid 3.Maintaining pressure 4.Inflating the membrane (optional) 5.Loosening filter plates 6.sludge discharge
Product feature
5.Easy operation, reliable, easy maintenance
1.The machine body is SUS 304. The target liquid won't be polluted and the machine is resistant to corrosion.
2.The filter cloth is embedded into filter plate to form sealing surface. There won't be any leakage during filtration.
2.The filter cloth is embedded into filter plate to form sealing surface. There won't be any leakage during filtration.
3.Filters of larger processing capacity can simply switch to filter smaller capacity liquid. Customers don't need to buy one or more extra smaller machine when facing multi task.
4.High efficiency, low power consumption,economic
5.Easy operation, reliable, easy maintenance
