Main Description | ||
Overall Dimension | 12400mm*2495mm*2920mm | |
Box Body Dimension | 12280mm*2300mm*600mm | |
Payload | 40T | |
Tare weight | 8000kg | |
Rear Overhang | 1930mm, 2130mm | |
King Pin Setting | 1460mm | |
Running Gear | ||
Suspension | Tri-axle mechanical suspension with 11-pcs leaf spring | |
Wheel Hubs | Cast steel, 10 studs | |
Tires | 11.00-20, 11.00R20,12.00-20,12.00R20, 12units | |
Axles | 3AQ,FUWA,JSAF, BPW or STEYR axle, load capacity 13T | |
Brakes | Dual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30+T30 air chamber; parking brake | |
Under Frame | Tri-axle 8-pcs leaf spring suspension with equalizer beam | |
Main Beam | I shape, Mild Alloy (16Mn) by Automatic submerged arc welding. | |
Cross Beam | Mild Alloy Q235 | |
King Pin | Size: 50# (2'') or 90#(3.5’’); Type: welded or assembled | |
Landing Gear | Single side operation or double side operation, Static capacity 30Ton | |
Electrical & Paint | ||
Lights & Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |
Wiring | 24V, 6 lines | |
Air/Elec. Connector | ISO standard air connector, 24V 7 pin plug socket | |
Paint | Sand blasting before painting, 2 coat of anticorrosive primer, 2 coats of finish urethane paint, Color upon request | |
