Hydraulic Straddle Leg Drum Handling Truck
US $178.00-$195.00
500kg Multifunction handle 55 gallon Electric drum lifter price
- Category: Other Material Handling Equipment >>>
- Supplier: Taizhou,Amity,Care,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
| Model | COT0316SD | COT0616SD | COT0520SD | COT0525SD | COT0530SD |
| Order Number | 9.03001 | 9.03002 | 9.03003 | 9.03004 | 9.03005 |
| Load Capacity(kg) | 300 | 600 | 500 | 500 | 500 |
| Max Lift height (mm) | 1600 | 1600 | 2000 | 2500 | 3000 |
| Min.height of clamp(mm | 540 | 540 | 540 | 540 | 540 |
| Drum size (mm) | φ580 *900 | φ580 *900 | φ580 *900 | φ580 *900 | φ580 *900 |
| Drum rotation (mm) | 180 | 180 | 180 | 180 | 180 |
| Battery (V/Ah) | 24/80 | 24/80 | 24/80 | 24/80 | 24/80 |
| Charger (V/A) | 24/15 | 24/15 | 24/15 | 24/15 | 24/15 |
| Lifting motor (Kw) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 |
| Driving motor (Kw) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| Weight (Kg) | 510 | 520 | 530 | 540 | 550 |
| Overall size (mm)L*W*H | 1800*1000*2000 | 1800*1000*2000 | 1800*1000*1580 | 1800*1000*1780 | 1800*1000*2050 |
| Driving wheel (mm) | 1*¢200*70 | ||||
| Training wheels (mm) | 2*¢150*50 | ||||
| Front wheels (mm) | 4*¢80*70 | ||||
| Climbing slope (%) | 43561 | ||||
| Channel request (mm) | 1900Turn,1100Forward and Backward | ||||
| Travel speed | 4/6 Km/h | ||||
| Lifting speed | 45/50 mm/s | ||||
| Falling speed | 45/40 mm/s | ||||
| Braking type | Electromagenetic braking | ||||
1:Be used to moving,lifing,load and tilt 55GAL steel drum.
2:Multifunction handle,stepless speed change,High-power reversing switch and integration pump station.
3:Stand up operation type ,easier to use.
4:Manual clamp,electric hydraulic tilting ,long service time.
5:Simple operation,be wide used in chemical,printing and painting industry.
6:Use American Curtis electric controller with the characteristic of Flexible and Convenient ,can be controlled by a man.
