2liter HDPE plastic bottle manufacturing machines

Product Overview

Description

2liter HDPE automatic blow molding machine





Max. Product Volume	L	JN-2S2L
Dry cycle	PC/H	800*2
Screw diameter	MM	60
screw L/D ratio	L/D	24-26
screw motor power	KW	15
screw heating capacity	KW	3.3*4.5
No. of heating zone	Zone	3
output of HDPE	KG/H	50-70
oil pump driver power	KW	7.5
clamping force	KN	38
mold stroke	MM	138-368
size of mold(W*H)	MM	300*320
Moving distance	MM	370
Max. Die diameter(W*H)	MM	90
Die heat capacity	KW	1.8-3.5
Blowing pressure	MPA	0.6-0.8
Air volume	M3/Min	0.4
Cooling water pressure	MPA	0.3
water consumption	L/Min	50
weight of machine	Ton	4.5
size of machine	M	3*2*2.1
