Product Overview
Description
JIECANG 600mm Stroke 24VDC Motor Actuator Gate Opener Waterproof Electric Linear Actuator
Products Description
Features
1. DC 24V permanent magnet motor;
2. The maximum thrust is 6000N, the maximum pull is 4000N
3. The shell color is gray or black optional
4. Protection IP43
5. The inner tube adopts stainless steel tube
6. Low noise, the average noise level is lower than 48dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. High-strength front and rear fixing device
9. Passed certification: CE, UL
2. The maximum thrust is 6000N, the maximum pull is 4000N
3. The shell color is gray or black optional
4. Protection IP43
5. The inner tube adopts stainless steel tube
6. Low noise, the average noise level is lower than 48dB (environmental noise≤40dB)
7. Built-in electronic limit switch
8. High-strength front and rear fixing device
9. Passed certification: CE, UL
Options
·Safety nut: optional
·Only push no pull function: optional
·Hall sensor feedback: optional
·Reed switch feedback: optional
Usage
Duty cycle of work: 10%; work for 2 minutes, rest for 18 minutes
Operating temperature: 5~40℃
Storage temperature: -10~50℃
Supporting controller: can be matched with Jiechang standard controller
Relative humidity: 20%-90% at 25°C, non-condensing
Atmospheric pressure: 700-1060hPa
Operating temperature: 5~40℃
Storage temperature: -10~50℃
Supporting controller: can be matched with Jiechang standard controller
Relative humidity: 20%-90% at 25°C, non-condensing
Atmospheric pressure: 700-1060hPa
Company Profile
FAQ
Q: Do you get the relevant certifications?
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
A: Yes, so far, we have got certification of CE, TUV, UL, PSE, KC, SAA, ROSH, ISO9001:2015, ISO14001:2015 and so on.
Q: May I have a sample order before bulk one?
A: Of course, we can provide a sample for you.
Q: What is the shipping port?
A: Shanghai or Ningbo Port.
Q: How can I get the quotation?
A: You need to send up information, we will let our regional sales to contact with you, and the details you should to give: email address, telephone number, material, size, input, Load capacity, quantity, color, speed or frequency, etc
